Basler Electric DGC-2020HD Modbus Protocol Benutzerhandbuch
Seite 218
212
9469375991 Rev A
Standardregistertabelle
DGC-2020HD Modbus
™ Protokoll
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-6
Kurvenindex
SG2 1P 24470
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-6
Richtung
SG2 1P 24472
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-6
Sofortiges Zurücksetzen
verwenden
SG2 1P 24474
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-6
Konstante TD
SG2 1P 24476
Float
4
R W n.z.
0 - 9.9
51-6
Konstante A
SG2 1P 24478
Float
4
R W n.z.
0 - 600
51-6
Konstante B
SG2 1P 24480
Float
4
R W n.z.
0 - 25
51-6
Konstante C
SG2 1P 24482
Float
4
R W n.z.
0 - 1
51-6
Konstante N
SG2 1P 24484
Float
4
R W n.z.
0.5 - 2.5
51-6
Konstante R
SG2 1P 24486
Float
4
R W n.z.
0 - 30
51-6
Spannungsbegrenzung Sollwert SG2 1P 24488
Float
4
R W Volt
30 - 250
51-6
Spannungsbegrenzung Modus
SG2 1P 24490
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-6
Alarmkonfiguration
SG2 1P 24492
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-6
Niedrige Leitung Skalierung
SG2 1P 24494
Float
4
R W n.z.
0,001 - 3
51-6
Spannungsbegrenzung Quelle
SG2 1P 24496
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-6
Konstante Q
SG2 1P 24498
Float
4
R W n.z.
0.1 - 10
51-6
Modus
SG2 3P 24500
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-6
Quelle
SG2 3P 24502
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-6
Abgriff
SG2 3P 24504
Float
4
R W Amp
0.9 - 7.75
51-6
Kurvenindex
SG2 3P 24506
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-6
Richtung
SG2 3P 24508
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-6
Sofortiges Zurücksetzen
verwenden
SG2 3P 24510
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-6
Konstante TD
SG2 3P 24512
Float
4
R W n.z.
0 - 9.9
