Basler Electric DGC-2020HD Modbus Protocol Benutzerhandbuch
Seite 210
204
9469375991 Rev A
Standardregistertabelle
DGC-2020HD Modbus
™ Protokoll
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-5
Konstante A
SG0 3P 24082
Float
4
R W n.z.
0 - 600
51-5
Konstante B
SG0 3P 24084
Float
4
R W n.z.
0 - 25
51-5
Konstante C
SG0 3P 24086
Float
4
R W n.z.
0 - 1
51-5
Konstante N
SG0 3P 24088
Float
4
R W n.z.
0.5 - 2.5
51-5
Konstante R
SG0 3P 24090
Float
4
R W n.z.
0 - 30
51-5
Spannungsbegrenzung Sollwert SG0 3P 24092
Float
4
R W Volt
30 - 250
51-5
Spannungsbegrenzung Modus
SG0 3P 24094
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-5
Alarmkonfiguration
SG0 3P 24096
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-5
Niedrige Leitung Skalierung
SG0 3P 24098
Float
4
R W n.z.
0,001 - 3
51-5
Spannungsbegrenzung Quelle
SG0 3P 24100
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-5
Konstante Q
SG0 3P 24102
Float
4
R W n.z.
0.1 - 10
51-5
Modus
SG1 1P 24104
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-5
Quelle
SG1 1P 24106
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-5
Abgriff
SG1 1P 24108
Float
4
R W Amp
0.9 - 7.75
51-5
Kurvenindex
SG1 1P 24110
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-5
Richtung
SG1 1P 24112
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-5
Sofortiges Zurücksetzen
verwenden
SG1 1P 24114
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-5
Konstante TD
SG1 1P 24116
Float
4
R W n.z.
0 - 9.9
51-5
Konstante A
SG1 1P 24118
Float
4
R W n.z.
0 - 600
51-5
Konstante B
SG1 1P 24120
Float
4
R W n.z.
0 - 25
51-5
Konstante C
SG1 1P 24122
Float
4
R W n.z.
0 - 1
51-5
Konstante N
SG1 1P 24124
Float
4
R W n.z.
0.5 - 2.5
51-5
Konstante R
SG1 1P 24126
Float
4
R W n.z.
0 - 30
51-5
Spannungsbegrenzung Sollwert SG1 1P 24128
Float
4
R W Volt
30 - 250
51-5
Spannungsbegrenzung Modus
SG1 1P 24130
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-5
Alarmkonfiguration
SG1 1P 24132
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-5
Niedrige Leitung Skalierung
SG1 1P 24134
Float
4
R W n.z.
0,001 - 3
51-5
Spannungsbegrenzung Quelle
SG1 1P 24136
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-5
Konstante Q
SG1 1P 24138
Float
4
R W n.z.
0.1 - 10
