Basler Electric DGC-2020HD Modbus Protocol Benutzerhandbuch
Seite 200
194
9469375991 Rev A
Standardregistertabelle
DGC-2020HD Modbus
™ Protokoll
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-3
Kurvenindex
SG2 1P 23606
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-3
Richtung
SG2 1P 23608
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-3
Sofortiges Zurücksetzen
verwenden
SG2 1P 23610
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-3
Konstante TD
SG2 1P 23612
Float
4
R W n.z.
0 - 9.9
51-3
Konstante A
SG2 1P 23614
Float
4
R W n.z.
0 - 600
51-3
Konstante B
SG2 1P 23616
Float
4
R W n.z.
0 - 25
51-3
Konstante C
SG2 1P 23618
Float
4
R W n.z.
0 - 1
51-3
Konstante N
SG2 1P 23620
Float
4
R W n.z.
0.5 - 2.5
51-3
Konstante R
SG2 1P 23622
Float
4
R W n.z.
0 - 30
51-3
Spannungsbegrenzung Sollwert SG2 1P 23624
Float
4
R W Volt
30 - 250
51-3
Spannungsbegrenzung Modus
SG2 1P 23626
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-3
Alarmkonfiguration
SG2 1P 23628
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-3
Niedrige Leitung Skalierung
SG2 1P 23630
Float
4
R W n.z.
0,001 - 3
51-3
Spannungsbegrenzung Quelle
SG2 1P 23632
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-3
Konstante Q
SG2 1P 23634
Float
4
R W n.z.
0.1 - 10
51-3
Modus
SG2 3P 23636
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-3
Quelle
SG2 3P 23638
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-3
Abgriff
SG2 3P 23640
Float
4
R W Amp
0.9 - 7.75
51-3
Kurvenindex
SG2 3P 23642
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-3
Richtung
SG2 3P 23644
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-3
Sofortiges Zurücksetzen
verwenden
SG2 3P 23646
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-3
Konstante TD
SG2 3P 23648
Float
4
R W n.z.
0 - 9.9
