DGC-2020HD Modbus
™ Protokoll
Standardregistertabelle
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-1
Modus
SG1 3P 22988
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-1
Quelle
SG1 3P 22990
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-1
Abgriff
SG1 3P 22992
Float
4
R W Amp
0.9 - 7.75
51-1
Kurvenindex
SG1 3P 22994
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-1
Richtung
SG1 3P 22996
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-1
Sofortiges Zurücksetzen
verwenden
SG1 3P 22998
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-1
Konstante TD
SG1 3P 23000
Float
4
R W n.z.
0 - 9.9
51-1
Konstante A
SG1 3P 23002
Float
4
R W n.z.
0 - 600
51-1
Konstante B
SG1 3P 23004
Float
4
R W n.z.
0 - 25
51-1
Konstante C
SG1 3P 23006
Float
4
R W n.z.
0 - 1
51-1
Konstante N
SG1 3P 23008
Float
4
R W n.z.
0.5 - 2.5
51-1
Konstante R
SG1 3P 23010
Float
4
R W n.z.
0 - 30
51-1
Spannungsbegrenzung Sollwert SG1 3P 23012
Float
4
R W Volt
30 - 250
51-1
Spannungsbegrenzung Modus
SG1 3P 23014
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-1
Alarmkonfiguration
SG1 3P 23016
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-1
Niedrige Leitung Skalierung
SG1 3P 23018
Float
4
R W n.z.
0,001 - 3
51-1
Spannungsbegrenzung Quelle
SG1 3P 23020
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-1
Konstante Q
SG1 3P 23022
Float
4
R W n.z.
0.1 - 10
51-1
Modus
SG2 1P 23024
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-1
Quelle
SG2 1P 23026
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-1
Abgriff
SG2 1P 23028
Float
4
R W Amp
0.9 - 7.75
