Basler Electric DGC-2020HD Modbus Protocol Benutzerhandbuch
Seite 285
9469375991 Rev A
279
DGC-2020HD Modbus
™ Protokoll
Alte Registertabelle
Register
Beschreibung
Typ
Einheiten
Skalierungsfaktor R/W
Bereich
45570-71
Konfigurierbarer Schutz Alarm Bits
Uint32 n.z.
n.z.
R
Bit 0 = Konf. Schutz 8 Unter 2
Bit 1 = Konf. Schutz 8 Unter 1
Bit 2 = Konf. Schutz 8 Über 2
Bit 3 = Konf. Schutz 8 Über 1
Bit 4 = Konf. Schutz 7 Unter 2
Bit 5 = Konf. Schutz 7 Unter 1
Bit 6 = Konf. Schutz 7 Über 2
Bit 7 = Konf. Schutz 7 Über 1
Bit 8 = Konf. Schutz 6 Unter 2
Bit 9 = Konf. Schutz 6 Unter 1
Bit 10 = Konf. Schutz 6 Über 2
Bit 11 = Konf. Schutz 6 Über 1
Bit 12 = Konf. Schutz 5 Unter 2
Bit 13 = Konf. Schutz 5 Unter 1
Bit 14 = Konf. Schutz 5 Über 2
Bit 15 = Konf. Schutz 5 Über 1
Bit 16 = Konf. Schutz 4 Unter 2
Bit 17 = Konf. Schutz 4 Unter 1
Bit 18 = Konf. Schutz 4 Über 2
Bit 19 = Konf. Schutz 4 Über 1
Bit 20 = Konf. Schutz 3 Unter 2
Bit 21 = Konf. Schutz 3 Unter 1
Bit 22 = Konf. Schutz 3 Über 2
Bit 23 = Konf. Schutz 3 Über 1
Bit 24 = Konf. Schutz 2 Unter 2
Bit 25 = Konf. Schutz 2 Unter 1
Bit 26 = Konf. Schutz 2 Über 2
Bit 27 = Konf. Schutz 2 Über 1
Bit 28 = Konf. Schutz 1 Unter 2
Bit 29 = Konf. Schutz 1 Unter 1
Bit 30 = Konf. Schutz 1 Über 2
Bit 31 = Konf. Schutz 1 Über 1
45572-73
Konfigurierbarer Schutz Voralarm Bits
Uint32 n.z.
n.z.
R
Bit 0 = Konf. Schutz 8 Unter 2
Bit 1 = Konf. Schutz 8 Unter 1
Bit 2 = Konf. Schutz 8 Über 2
Bit 3 = Konf. Schutz 8 Über 1
Bit 4 = Konf. Schutz 7 Unter 2
Bit 5 = Konf. Schutz 7 Unter 1
Bit 6 = Konf. Schutz 7 Über 2
Bit 7 = Konf. Schutz 7 Über 1
Bit 8 = Konf. Schutz 6 Unter 2
Bit 9 = Konf. Schutz 6 Unter 1
Bit 10 = Konf. Schutz 6 Über 2
Bit 11 = Konf. Schutz 6 Über 1
Bit 12 = Konf. Schutz 5 Unter 2
Bit 13 = Konf. Schutz 5 Unter 1
Bit 14 = Konf. Schutz 5 Über 2
Bit 15 = Konf. Schutz 5 Über 1
Bit 16 = Konf. Schutz 4 Unter 2
Bit 17 = Konf. Schutz 4 Unter 1
Bit 18 = Konf. Schutz 4 Über 2
Bit 19 = Konf. Schutz 4 Über 1
Bit 20 = Konf. Schutz 3 Unter 2
Bit 21 = Konf. Schutz 3 Unter 1
Bit 22 = Konf. Schutz 3 Über 2
Bit 23 = Konf. Schutz 3 Über 1
Bit 24 = Konf. Schutz 2 Unter 2
Bit 25 = Konf. Schutz 2 Unter 1
Bit 26 = Konf. Schutz 2 Über 2
Bit 27 = Konf. Schutz 2 Über 1
Bit 28 = Konf. Schutz 1 Unter 2
Bit 29 = Konf. Schutz 1 Unter 1
Bit 30 = Konf. Schutz 1 Über 2
Bit 31 = Konf. Schutz 1 Über 1
45574
Gen KVAr A
Int32
kVAr
n.z.
R
(-2147483648) - 2147483647
45576
Gen KVAr B
Int32
kVAr
n.z.
R
(-2147483648) - 2147483647
45578
Gen KVAr C
Int32
kVAr
n.z.
R
(-2147483648) - 2147483647
45580
Gen KVAr Gesamt
Int32
kVAr
n.z.
R
(-2147483648) - 2147483647
45582
Reserviert
