Standardregistertabelle
DGC-2020HD Modbus
™ Protokoll
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-2
Modus
SG3 3P 23420
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-2
Quelle
SG3 3P 23422
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-2
Abgriff
SG3 3P 23424
Float
4
R W Amp
0.9 - 7.75
51-2
Kurvenindex
SG3 3P 23426
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-2
Richtung
SG3 3P 23428
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-2
Sofortiges Zurücksetzen
verwenden
SG3 3P 23430
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-2
Konstante TD
SG3 3P 23432
Float
4
R W n.z.
0 - 9.9
51-2
Konstante A
SG3 3P 23434
Float
4
R W n.z.
0 - 600
51-2
Konstante B
SG3 3P 23436
Float
4
R W n.z.
0 - 25
51-2
Konstante C
SG3 3P 23438
Float
4
R W n.z.
0 - 1
51-2
Konstante N
SG3 3P 23440
Float
4
R W n.z.
0.5 - 2.5
51-2
Konstante R
SG3 3P 23442
Float
4
R W n.z.
0 - 30
51-2
Spannungsbegrenzung Sollwert SG3 3P 23444
Float
4
R W Volt
30 - 250
51-2
Spannungsbegrenzung Modus
SG3 3P 23446
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-2
Alarmkonfiguration
SG3 3P 23448
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-2
Niedrige Leitung Skalierung
SG3 3P 23450
Float
4
R W n.z.
0,001 - 3
51-2
Spannungsbegrenzung Quelle
SG3 3P 23452
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-2
Konstante Q
SG3 3P 23454
Float
4
R W n.z.
0.1 - 10
51-3
Modus
SG0 1P 23456
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-3
Quelle
SG0 1P 23458
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-3
Abgriff
SG0 1P 23460
Float
4
R W Amp
0.9 - 7.75
