Standardregistertabelle

DGC-2020HD Modbus

™ Protokoll

Name

Beschreibung

Gruppe Register

Typ

Bytes R/W Einheit

Bereich

AEM 1 Externer
Analogausgang 2

Param Maximum

GG

7360

Float

4

R W n.z.

-999999 - 999999

AEM 1 Externer
Analogausgang 2

Strom Minimum

GG

7362

Float

4

R W Milliamp 4 - 20

AEM 1 Externer
Analogausgang 2

Strom Maximum

GG

7364

Float

4

R W Milliamp 4 - 20

AEM 1 Externer
Analogausgang 2

Spannung Minimum

GG

7366

Float

4

R W Volt

0 - 10

AEM 1 Externer

Analogausgang 2

Spannung Maximum

GG

7368

Float

4

R W Volt

0 - 10

AEM 1 Externer

Analogausgang 2

Alarmkonfiguration

GG

7370

Uint32 4

R W n.z.

Nur Status=0

Voralarm=1
Alarm=2

AEM 1 Externer
Analogausgang 3

Parameterauswahl

GG

7372

Int32

4

R W n.z.

Kein Parameter=0
Öldruck=1

Kühlmitteltemp.=2
Batteriespannung=3

RPM=4

Kraftstoffpegel=5
Gen Hz=6

Gen VAB=7
Gen VBC=8

Gen VCA=9
Gen Vavg LL=10

Gen VAN=11

Gen VBN=12
Gen VCN=13

Gen Vavg LN=14
Bus 1 Hz=15

Bus 1 VAB=16
Bus 1 VBC=17

Bus 1 VCA=18

Bus 1 Vavg LL=19
Bus 1 VA=20

Bus 1 VB=21
Bus 1 VC=22

Bus 1 Vavg LN=23
Bus 2 Hz=24

Bus 2 VAB=25

Bus 2 VBC=26
Bus 2 VCA=27

Bus 2 Vavg LL=28
Bus 2 VAN=29

Bus 2 VBN=30
Bus 2 VCN=31

Bus 2 Vavg LN=32
Gen PF=33

Bus 1 PF=34

Bus 2 PF=35
Gen Pos kWh=36

Gen Neg kWh=37
Bus 1 Pos kWh=38

Bus 1 Neg kWh=39
Bus 2 Pos kWh=40

Bus 2 Neg kWh=41

Gen IA=42
Gen IB=43

Gen IC=44
Gen I Avg=45

Bus 1 IA=46
Bus 1 IB=47

Bus 1 IC=48

Bus 1 Iavg=49
Bus 2 IAN=50

Bus 2 IBN=51
Bus 2 ICN=52

Bus 2 Iavg=53
IG=54

I Aux=55
Gen kW A=56

Gen kW B=57

Gen kW C=58
Gen kW gesamt=59

Bus 1 kW A=60
Bus 1 kW B=61

Bus 1 kW C=62
Bus 1 kW gesamt=63

Bus 2 kW A=64

Bus 2 kW B=65
Bus 2 kW C=66

Bus 2 kW gesamt=67
Gen kVA A=68
