Basler Electric DGC-2020HD Modbus Protocol Benutzerhandbuch
Seite 198
192
9469375991 Rev A
Standardregistertabelle
DGC-2020HD Modbus
™ Protokoll
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-3
Konstante A
SG0 3P 23506
Float
4
R W n.z.
0 - 600
51-3
Konstante B
SG0 3P 23508
Float
4
R W n.z.
0 - 25
51-3
Konstante C
SG0 3P 23510
Float
4
R W n.z.
0 - 1
51-3
Konstante N
SG0 3P 23512
Float
4
R W n.z.
0.5 - 2.5
51-3
Konstante R
SG0 3P 23514
Float
4
R W n.z.
0 - 30
51-3
Spannungsbegrenzung Sollwert SG0 3P 23516
Float
4
R W Volt
30 - 250
51-3
Spannungsbegrenzung Modus
SG0 3P 23518
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-3
Alarmkonfiguration
SG0 3P 23520
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-3
Niedrige Leitung Skalierung
SG0 3P 23522
Float
4
R W n.z.
0,001 - 3
51-3
Spannungsbegrenzung Quelle
SG0 3P 23524
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-3
Konstante Q
SG0 3P 23526
Float
4
R W n.z.
0.1 - 10
51-3
Modus
SG1 1P 23528
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-3
Quelle
SG1 1P 23530
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-3
Abgriff
SG1 1P 23532
Float
4
R W Amp
0.9 - 7.75
51-3
Kurvenindex
SG1 1P 23534
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-3
Richtung
SG1 1P 23536
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-3
Sofortiges Zurücksetzen
verwenden
SG1 1P 23538
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-3
Konstante TD
SG1 1P 23540
Float
4
R W n.z.
0 - 9.9
51-3
Konstante A
SG1 1P 23542
Float
4
R W n.z.
0 - 600
51-3
Konstante B
SG1 1P 23544
Float
4
R W n.z.
0 - 25
51-3
Konstante C
SG1 1P 23546
Float
4
R W n.z.
0 - 1
51-3
Konstante N
SG1 1P 23548
Float
4
R W n.z.
0.5 - 2.5
51-3
Konstante R
SG1 1P 23550
Float
4
R W n.z.
0 - 30
51-3
Spannungsbegrenzung Sollwert SG1 1P 23552
Float
4
R W Volt
30 - 250
51-3
Spannungsbegrenzung Modus
SG1 1P 23554
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-3
Alarmkonfiguration
SG1 1P 23556
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-3
Niedrige Leitung Skalierung
SG1 1P 23558
Float
4
R W n.z.
0,001 - 3
51-3
Spannungsbegrenzung Quelle
SG1 1P 23560
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-3
Konstante Q
SG1 1P 23562
Float
4
R W n.z.
0.1 - 10
