Basler Electric DGC-2020HD Modbus Protocol Benutzerhandbuch
Seite 186
180
9469375991 Rev A
Standardregistertabelle
DGC-2020HD Modbus
™ Protokoll
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-1
Konstante A
SG0 3P 22930
Float
4
R W n.z.
0 - 600
51-1
Konstante B
SG0 3P 22932
Float
4
R W n.z.
0 - 25
51-1
Konstante C
SG0 3P 22934
Float
4
R W n.z.
0 - 1
51-1
Konstante N
SG0 3P 22936
Float
4
R W n.z.
0.5 - 2.5
51-1
Konstante R
SG0 3P 22938
Float
4
R W n.z.
0 - 30
51-1
Spannungsbegrenzung Sollwert SG0 3P 22940
Float
4
R W Volt
30 - 250
51-1
Spannungsbegrenzung Modus
SG0 3P 22942
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-1
Alarmkonfiguration
SG0 3P 22944
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-1
Niedrige Leitung Skalierung
SG0 3P 22946
Float
4
R W n.z.
0,001 - 3
51-1
Spannungsbegrenzung Quelle
SG0 3P 22948
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-1
Konstante Q
SG0 3P 22950
Float
4
R W n.z.
0.1 - 10
51-1
Modus
SG1 1P 22952
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-1
Quelle
SG1 1P 22954
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-1
Abgriff
SG1 1P 22956
Float
4
R W Amp
0.9 - 7.75
51-1
Kurvenindex
SG1 1P 22958
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-1
Richtung
SG1 1P 22960
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-1
Sofortiges Zurücksetzen
verwenden
SG1 1P 22962
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-1
Konstante TD
SG1 1P 22964
Float
4
R W n.z.
0 - 9.9
51-1
Konstante A
SG1 1P 22966
Float
4
R W n.z.
0 - 600
51-1
Konstante B
SG1 1P 22968
Float
4
R W n.z.
0 - 25
51-1
Konstante C
SG1 1P 22970
Float
4
R W n.z.
0 - 1
51-1
Konstante N
SG1 1P 22972
Float
4
R W n.z.
0.5 - 2.5
51-1
Konstante R
SG1 1P 22974
Float
4
R W n.z.
0 - 30
51-1
Spannungsbegrenzung Sollwert SG1 1P 22976
Float
4
R W Volt
30 - 250
51-1
Spannungsbegrenzung Modus
SG1 1P 22978
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-1
Alarmkonfiguration
SG1 1P 22980
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-1
Niedrige Leitung Skalierung
SG1 1P 22982
Float
4
R W n.z.
0,001 - 3
51-1
Spannungsbegrenzung Quelle
SG1 1P 22984
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-1
Konstante Q
SG1 1P 22986
Float
4
R W n.z.
0.1 - 10
