Configuring the matrix switch « Matrix switch
8 · G&D CompactCenter X2
6. Use the Interface A (Network A interface) or Interface B (Network B interface) para-
graphs to enter the following data.
7. Press F2 to save your settings.
Configuring global network settings
Global network settings ensure even in complex networks that the matrix switch is
available from all sub networks.
How to configure global network settings:
1. Use a user module to press the Ctrl+Num (default) hotkey to open the on-screen
display of the KVM matrix system.
2. Press F11 to call the Configuration menu.
3. Select the Network row and press Enter .
4. Enter the following data to the Main Network paragraph:
5. Press F2 to save your settings.
Operational
mode:
Press F8 to select the operational mode of the Network A or Net-
work B interfaces:
 Off: switches off network interface.
 Static: uses static settings.
 DHCP: obtains the settings from a DHCP server.
IP address: Enter the IP address of the interface .
No inputs are possible in the DHCP operational mode.
Netmask: Enter the netmask of the network.
No inputs are possible in the DHCP operational mode.
Connection type: Press F8 to define if the connection type is to be negotiated
with the remote device ( Auto ) or select one of the listed types.
Global
preferences:
Press F8 to select the operational mode:
 Static: uses static settings.
 DHCP: obtains the settings from a DHCP server
Hostname: Enter the hostname of the matrix switch.
Domain: Enter the domain the device is to belong to.
Gateway: Enter the gateway IP address.
DNS Server 1: Enter the DNS server IP address.
DNS Server 2: Optionally, enter the IP address of another DNS server.
