CATpro2-Audio-USB « Target modules
22 · G&D CompactCenter X2
Status displays
The blinking Transmission LED indicates the following operating states:
Technical data
Status Transmission LED
Time in seconds
A connection to the KVM matrix system could not be established.
Check if the target module is properly connected to the
KVM matrix system.
A connection to KVM matrix system has been established.
No user module is currently accessing.
A connection to KVM matrix system has been established.
A user module is currently accessing.
A connection to KVM matrix system has been established.
A user module is currently accessing and keyboard and mouse data
are being received.
[flickering]
Video Signal type: analog video
Audio Resolution: 24 bit
Sampling rate: 48 kHz
Bandwidth: 20 kHz
Interfaces to target computer:  1 × USB-A
 1 × D-Sub HD 15
 1 × Klinkenstecker
to matrix switch:  1 × RJ45 socket
Total length Target module incl. cable: 0,3 meters
Power supply Type: via USB interface of the target computer
Connection: USB
Voltage: +5VDC
Casing Material: plastics
Dimensions (W × H × D): 45 × 20,7 × 70 mm
Weight: ca. 120 g
Operating envi-
ronment
Temperature: +5 bis +40 °C
Air humidity: < 80%, non-condensing
Conformity CE, RoHs
0 1 2 3
