Kohler Free Freight RKPX60390 - Handbuch (Seite 14)

722
Order Factory Direct 800-528-3446
Fax 520-294-1045 • www.rrproducts.com
Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
Air Intake - Group 1
1 RKX1672 X-167-2 Kohler Screw, H.C. 10-32 x 5/16 3 0.47
2 RKX2767 X-276-7 Kohler Nut, Wing 1 0.39
3 RK235101 235101 Kohler Base, Air Cleaner 1 23.05
4 RK235102 235102 Kohler Cover, Air Cleaner 1 19.40
5 RK235116 235116 Kohler Element 1 8.95
6 RK275341 275341 Kohler Gasket, Air Horn 1 2.05
7 RK237421 237421 Kohler Precleaner Element 1 3.85
8 RKA235100 A-235100 Kohler Air Cleaner Assy. 1 50.55
RK2511307 25 113 07 Kohler Decal, Air Cleaner 1 1.00
(Not Illustrated)
Baffles & Shroud - Group 2
1 RKX2553 X-25-53 Kohler Washer 1 0.81
2 RKX1322 X-132-2 Kohler Screw, H.C. 1/4-20 x 3/4 5 0.99
3 RKX1326 X-132-6 Kohler Screw, H.C. 1/4-20 x 1/2 2 0.81
4 RK235652 235652 Kohler Baffle, Side Air 1 6.60
5 RK236676 236676 Kohler Baffle, Cylinder 1 8.05
6 RK4702718 47 027 18 Kohler Housing, Blower 1 104.05
7 RK237677 237677 Kohler Baffle, Head 1 15.30
8 RKX1435 X-143-5 Kohler Screw, H.C. w/star washer 1 0.99
sems 1/4-20 x 5/8
Breather & Vent - Group 3
1 RK275144 275144 Kohler Gasket 1 2.60
2 RKX7991 X-799-1 Kohler Palnut 1 0.96
3 RK231032 231032 Kohler Seal, Breather 1 2.70
4 RK235047 235047 Kohler Reed, Breather 1 5.90
5 RK235048 235048 Kohler Gasket, Valve Cover 1 2.30
6 RK235117 235117 Kohler Baffle, Breather 1 2.40
7 RK235118 235118 Kohler Filter, Breather 1 5.90
8 RK275220 275220 Kohler Stud, Valve Cover 1 3.65
9 RK235631 235631 Kohler Plate, Breather 1 12.70
10 RKA235418 A-235418-S Kohler Cover, Valve, Incl. #6 & 7 1 10.85
Camshaft & Valves - Group 4
1 RK230020 230020 Use RK5241301
1 RK5241301 52 413 01 Kohler Rotator 2 11.45
2 RK235011 235011 Kohler Retainer, Spring Upper 2 2.05
3 RK235168 235168 Kohler Spring, Valve 2 5.90
4 RK235193 235193 Use RK4738009
4 RK4738009 47 380 09 Kohler Pin, Camshaft 1 8.60
5 RKD235327 D-235327 Kohler Tappet 2 19.30
6 RK235008 235008 Kohler Valve, Intake 1 26.05
7 RK235826 235826 Kohler Valve, Exhaust 1 22.80
8 RK4175510 41 755 10 Kohler Kit, Retainer 2 4.10
9 RK275066 275066 Kohler Spacer, Camshaft .005 A/R 2.70
9 RK275067 275067 Kohler Spacer, Camshaft .010 A/R 2.70
10 RK4701009 47 010 09 Kohler Camshaft Assy. 1 94.25
11 RK4708901 47 089 01 Kohler Spring, Actuating 1 3.50
11
10
9
4
7
6
8
2
3
1
5
1
3
2
3
6
7
8
10
1
4
9
5
2
6
2
3
1
7
4
5
8
2
3
4
5
7
8
1
6
Model K301S Spec. 47827
Fits National Mower
