Kohler Free Freight RKPX60390 - Handbuch (Seite 34)

883
Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
2
3
5
6
4
1
14
1
8
13
11
10
9
2
5 3
6
4
7
4
3
2
1
5
2
3
4
6
1
5
8
9
7
10
2
1
Model M16QS Spec. 711563
Fits Toro Reelmaster 216
Cylinder Head - Group 9
1 RK4504117 45 041 17 Kohler Gasket, Cylinder Head 1 9.60
2 RK4501509 45 015 09 Kohler Head, Cylinder 1 118.15
3 RK270158 270158 Kohler Screw, H.C. 3/8-16 x 1 1/2 9 2.70
4 RK4708617 47 086 17 Kohler Screw, Hex. Socket Hd. 1 12.60
3/8-16 x 1
5 RK270889 270889 Kohler Washer 10 2.70
6 RK4744502 47 445 02 Kohler Strap, Lifting 1 2.05
Dipstick - Group 10
1 RK4702906 47 029 06 Kohler Tube, Oil Fill 1 39.10
2 RK4703827 47 038 27 Kohler Dipstick 1 11.15
3 RK237064 237064 Kohler Gasket 1 3.35
4 RKX1312 X-131-2 Kohler Screw, R.H. 3 0.47
5 RK4115301 41 153 01 Kohler O-Ring 1 1.80
Electric Start - Group 11
1 RK4712629 47 126 29 Kohler Bracket, Solenoid 1 13.55
2 RKX1592 X-159-2 Kohler Screw, H.C. Sems 3/8-16x1 2 1.30
3 RK4512617 45 126 17 Kohler Brace, Tail 1 2.30
4 RKX6762 X-67-62 Kohler Screw, Hex. Wash. Hd. 1 0.83
1/4-20x3/4
5 RKX6783 X-67-83 Kohler Screw, Hex. Wash. Hd. 1 0.23
1/4-20x3/8
6 RK2545003 25 450 03 Kohler Tag, Caution 1 0.42
7 RK4109806 41 098 04 Kohler Starter Assy 1 148.50
8 RK4108619 41 086 19 Kohler Bolt, Thru 1/4-20x5 1/16 2 9.75
9 RK4175533 47 755 07 Kohler Kit, Drive 1 77.65
10 RK4175533 41 755 33 Kohler Kit, Drive Parts 1 77.65
11 RK4108105 41 227 03 Kohler Cap, Drive End 1 40.30
13 RK5222703 41 227 04 Discontinued 1
14 RK8275528 52 755 15 Kohler Kit, Brush 1 34.80
Exhaust - Group 12
1 RK4505404 45 054 04 Kohler Elbow, Exhaust 1 34.60
2 RK4510001 45 100 01 Kohler Nut, Lock 1 5.90
Flywheel - Group 13
1 RKX463 X-46-3 Kohler Key, Woodruff 3/16x1 1 0.93
2 RK4702553 47 025 53 Kohler Flywheel 1 277.95
3 RK5246815 52 468 15 Kohler Washer, Plain 13/32 I.D., 1 2.05
1 3/8 O.D.
4 RK2508624 25 086 24 Kohler Screw, Hex. Mach. 1 1.25
3/8-24x1 1/8
5 RK2515701 25 157 01 Kohler Fan 1 32.40
6 RK2511204 25 112 04 Kohler Spacer 17/64 I.D., 3/8 O.D. 4 1.25
15/64 lg.
7 RK2508621 25 086 21 Kohler Screw, Hex. Wash. Hd. 4 1.20
1/4-20x5/8
8 RK2516203 25 162 03 Kohler Screen, Grass 1 9.75
9 RK235954 235954 Kohler Shaft, Front Drive 1 148.30
10 RKX1592 X-159-2 Kohler Screw, H.C. 1 1.30
