Crankshaft - Group 8
1 RKX26934 X-269-34 Kohler Retainer 2 0.73
2 RK4714216 47 142 16 Kohler Crankshaft 1 242.90
3 RK4504303 45 043 03 Kohler Gear Assy. 2 65.45
4 RK4703001 47 030 01 Kohler Bearing, Needle 2 8.75
5 RK4775501 47 755 01 Kohler Kit, Spacer 1 22.75
6 RK10355 10355 Kohler Timing Tool, 1 8.75
Counter Balance Gears
Cylinder Head - Group 9
1 RK237522 237522 Kohler Stud A/R 5.80
2 RK237658 237658 Use RK4704115
2 RK4704115 47 041 15 Kohler Gasket, Cylinder Head 1 9.35
3 RK237670 237670 Kohler Head, Cylinder 1 113.25
4 RK270158 270158 Kohler Screw, H.C. 3/8-16 x 1 1/2 A/R 2.70
5 RK270721 270721 Kohler Screw, H.C. A/R 3.65
6 RK270889 270889 Kohler Washer 9 2.70
7 RK4744501 47 445 01 Use RK4744502
7 RK4744502 47 445 02 Kohler Strap, Lifting 1 2.05
8 RK2510024 X-83-2 Kohler Nut, Hex 3/8-16 1 1.00
Dipstick - Group 10
1 RKA235092 A-235092 Kohler Dipstick 1 14.65
Electric Start - Group 11
1 RKX221 X-22-1 Kohler Washer 3/8 2 0.99
2 RK234948 234948 Kohler Screw, H.C. 3/8-16 x 1 11/32 2 3.00
3 RKA237534 A-237534 Use RK4509807
3 RK4509809 45 098 07 Kohler Starter Assy 1 139.85
4 RK4575515 47 755 07 Kohler Kit, Drive 1 79.25
6 RK4508105 4508105 Kohler Cap, Drive End 1 40.30
7 RK4717001 47 170 01 Kohler Armature 1 158.25
9 RK237649 237649 Kohler Thru Bolt with Washer 2 9.50
10 RK4875515 48 755 15 Use RK5275515
10 RK8275528 52 755 15 Kohler Kit, Brush 1 34.80 7
3
4
5
6
8
9
10
1
2
1
1 7
6
2
3
4
8
6
5
6
6
2
1
4
5
3
6
Model K301S Spec. 47827
Fits National Mower
Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
