Kohler Free Freight RKPX60390 - Handbuch (Seite 27)

830
Order Factory Direct 800-528-3446
Fax 520-294-1045 • www.rrproducts.com
Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
Carburetor - Group 5
1 RK4515501 45 155 01 Kohler Connector, Hose 1 3.35
2 RKX7701 X-770-1 Kohler Screw, Sltd. Hd. 2 1.30
3 RK4585307 45 853 07 Use 4585313
3 RK4585313 45 853 13 Kohler Kit, Carburetor 1 187.15
4 RK4504107 45 041 07 Kohler Gasket, Air Cleaner 1 2.05
6 RK4704901 47 049 01 Kohler Gasket, Carburetor 1 7.45
7 RK2508627 25 086 27 Kohler Screw, Throttle & Choke Plate 4 1.45
8 RK4514607 45 146 07 Kohler Plate, Choke 1 2.05
9 RK2519401 25 194 01 Kohler Ball, Choke Friction 1 4.40
10 RK2508903 25 089 03 Kohler Spring, Choke Friction 1 4.40
11 RK4714436 47 144 25 Kohler Shaft, Throttle w/Lever & Seal 1 12.55
12 RK4714610 47 146 10 Kohler Plate, Throttle 1 5.90
13 RK2508902 25 089 02 Kohler Spring, Idle Fuel 1 1.85
14 RK2536801 25 368 01 Kohler Needle, Idle Fuel Adj. 1 2.35
15 RK2508904 25 089 04 Kohler Spring, Idle Speed 1 3.85
16 RK2508626 25 086 26 Kohler Screw, Idle Speed Adj. 1 1.80
17 RK4709038 47 090 38 Kohler Lever Assembly, Choke 1 17.65
19 RK2504104 25 041 04 Kohler Gasket, Bowl 1 3.15
20 RK2575709 25 757 09 Kohler Kit, Float 1 11.30
21 RK2510401 25 104 01 Kohler Bowl, Fuel 1 9.15
22 RK2504103 25 041 03 Kohler Gasket, Bowl Retainer Screw 1 2.40
23 RK2510005 25 100 05 Kohler Screw, Bowl Retainer 1 1.60
24 RK2515505 25 155 05 Kohler Connector, Hose 1 18.55
27 RK2536803 25 368 03 Kohler Needle, Main Fuel 1 3.10
28 RK2508902 25 089 02 Kohler Spring, Main Fuel 1 1.85
RK2575711 25 757 11 Kohler Kit, Carburetor Repair 1 25.15
Crankcase - Group 7
1 RK4713901 47 139 01 Kohler Plug, Hex. Ctsk. 3/4 N.P.T.F 1 2.40
2 RK4704109 47 041 09 Kohler Gasket, Bearing Plate 1 1.55
3 RKX23011 X-230-11 Kohler Plug, Expansion 1 0.47
4 RK4703206 47 032 06 Kohler Seal, Front Oil 1 7.15
5 RK4703207 47 032 07 Kohler Seal, Rear Oil 1 7.15
6 RK235025 235025 Kohler Gasket, Camshaft Cover 1 3.50
7 RK235026 235026 Kohler Cover, Camshaft 1 8.05
8 RK4742205 47 422 05 Kohler Gasket, Shim A/R 1.45
9 RK235125 235125-S Kohler Shaft, Governor Gear 1 28.20
10 RK236559 236559 Kohler Shaft, Balance Gear Stub 2 11.60
11 RK235376 235376 Kohler Bearing, Ball 2 75.45
12 RK4714611 47 146 11 Kohler Plate, Bearing 1 106.05
13 RKX1326 X-132-6 Kohler Screw, H.C. 1/4-20 x 1/2 4 0.81
14 RKX1592 X-159-2 Kohler Screw, H.C. 3/8-16 x 1 4 1.30
15 RK4578228 45 782 28 Kohler Block, Cylinder Miniblock 1 885.75
16 RK230265 230265 Kohler Insert, Valve 2 30.00
17 RK235007 235007-S Kohler Guide, Valve 2 10.05
18 RK234866 234866 Kohler Bearing 1 2.70
12
11
2
8
10
4
14
13
7
6
9
3
18
11
5
16
17
15
1
11
2
8 10
15
14
4
6
7
13
9
12
16
1
17
3
20
21
22
23
24
28
19
7
27
Model M16S Spec. 711533
Fits Toro Greensmaster 3000
