Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
Model M16S Spec. 711533
Fits Toro Greensmaster 3000
Crankshaft - Group 8
1 RK4514236 45 142 36 Kohler Kit, Crankshaft 1 244.20
2 RKX26934 X-269-34 Kohler Retainer 2 0.73
3 RK4504303 45 043 03 Kohler Gear Assy. 2 65.45
4 RK4703001 47 030 01 Kohler Bearing, Needle 2 8.75
5 RK4775501 47 755 01 Kohler Kit, Spacer 1 22.75
Cylinder Head - Group 9
1 RK4504117 45 041 16 Kohler Gasket, Cylinder Head 1 9.60
2 RK4501509 45 015 09 Kohler Head, Cylinder 1 118.15
3 RK270158 270158 Kohler Screw, H.C. 3/8-16 x 1 1/2 9 2.70
4 RK4708617 47 086 17 Kohler Screw, Hex. Socket Hd. 1 12.60
3/8-16 x 1
5 RK270889 270889 Kohler Washer 10 2.70
6 RK4744502 47 445 02 Kohler Strap, Lifting 1 2.05
Dipstick - Group 10
1 RK4712314 47 123 14 Kohler Tube, Oil Fill 1 80.95
2 RK4727203 47 272 03 Kohler Dipstick 1 77.60
3 RK237064 237064 Kohler Gasket 1 3.35
4 RKX1312 X-131-2 Kohler Screw, F.H. sems 3 0.47
10-24 x 1/2
Electric Start - Group 11
1 RK4712629 47 126 29 Kohler Bracket, Solenoid 1 13.55
2 RKX1592 X-159-2 Kohler Screw, H.C. Sems 3/8-16x1 2 1.30
3 RK4512617 45 126 17 Kohler Brace, Tail 1 2.30
4 RKX6762 X-67-62 Kohler Screw, Hex. Wash. Hd. 1 0.83
1/4-20x3/4
5 RKX6783 X-67-83 Kohler Screw, Hex. Wash. Hd. 1 0.23
1/4-20x3/8
6 RK2545003 25 450 03 Kohler Tag, Caution 1 0.42
7 RK4109806 41 098 06 Kohler Starter Assy 1 148.50
8 RK4108619 41 086 19 Kohler Bolt, Thru 1/4-20x5 1/16 2 9.75
9 RK4175533 47 755 07 Kohler Kit, Drive 1 77.65
11 RK4108105 41 227 03 Kohler Cap, Drive End 1 40.30
13 RK5222703 41 227 04 Discontinued 1
14 RK8275528 52 755 15 Kohler Kit, Brush 1 34.80
5
2
4
3
1
2
3
5
6
4
1
4
1
2
3
14
1
8
13
11
10
9
2
5 3
6
4
7
