Kohler Free Freight RKPX60390 - Handbuch (Seite 21)

812
Order Factory Direct 800-528-3446
Fax 520-294-1045 • www.rrproducts.com
Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
4
5
6
1
2
7
Carburetor - Group 5
1 RK275231 275231 Kohler Needle, Idle Fuel Adjusting 1 6.25
2 RK2575703 25 757 03 Kohler Kit, Float (Incl #19) 1 9.25
3 RKX7701 X-770-1 Kohler Screw, Sltd. Hd. 2 1.30
4 RKA236919 A-236919 Kohler Bracket Assy., Choke 1 7.30
5 RK235603 235603 Kohler Clip, Choke Cable 1 2.05
6 RK4704901 47 049 01 Kohler Gasket, Carburetor 1 7.45
7 RK4705320 47 053 20 Use RK4785332 1
7 RK4785332 47 853 32 Kohler Carburetor Assy. 1 213.65
8 RK232555 232555 Kohler Spring, Idle Speed 1 3.50
9 RK232556 232556 Kohler Screw, Idle Speed Adjusting 1 2.70
10 RK200372 200372 Kohler Gasket, Bowl Retainer Screw 1 1.00
11 RK4710006 47 100 06 Kohler Screw, Bowl Retainer 1 3.00
12 RK235448 235448 Kohler Bowl 1 7.90
13 RK200376 200376 Kohler Pin 1 2.05
14 RK200375 200375 Kohler Gasket, Bowl 1 2.60
15 RK200383 200383 Kohler Spring, Main Fuel 1 2.10
16 RK4710301 47 103 01 Kohler Needle, Main Fuel Adjusting 1 10.85
17 RK200380 200380 Kohler Spring, Idle Fuel Adjusting 1 2.70
18 RK2575701 25 757 01 Kohler Kit, Carburetor Repair 1 11.50
19 RK2504102 25 041 02 Kohler Gasket, Bowl Baffle 1 2.70
20 RK237917 237917 Kohler Spring, Float 1 5.35
Crankcase - Group 7
1 RK4713901 47 139 01 Kohler Plug, Hex. ctsk. 3/4 N.P.T.F. 1 2.40
2 RKX1326 X-132-6 Kohler Screw, H.C. 1/4-20 x 1/2 4 0.81
3 RKX1592 X-159-2 Kohler Screw, H.C. 3/8-16 x 1 4 1.30
4 RKX23011 X-230-11 Kohler Plug 1 0.47
5 RK4703206 47 032 06 Kohler Seal, Front Oil 1 7.15
6 RK4703207 47 032 07 Kohler Seal, Rear Oil 1 7.15
7 RK235025 235025 Kohler Gasket, Cover 1 3.50
8 RK235026 235026 Kohler Cover, Camshaft 1 8.05
9 RK235070 235070 Kohler Gasket (A.R.) 1 2.40
10 RK235125 235125-S Kohler Shaft, Governor 1 28.20
11 RK235376 235376 Kohler Bearing, Ball 2 75.45
12 RK235757 235757 Kohler Gasket 1 4.10
13 RK236559 236559 Kohler Shaft 2 11.60
14 RK4515602 45 156 02 Kohler Plate, Bearing 1 126.40
15 RKB237836 B-237836 Use RK4778298
15 RK4778298 47 782 98 Kohler Block, Cylinder Miniblock 1 895.30
16 RK230265 230265 Kohler Insert, intake 2 30.00
17 RK235007 235007-S Kohler Guide, Valve 2 10.05
18 RK234866 234866 Kohler Bearing 1 2.70
8
9
10
11
12
13
14
15
16
17
20
3
9
11
12
13
14
3
5
4
6
7
8
10
15
16
17
18
11
2
1
19
18
Model K321S Spec. 60407
Fits Toro Greensmaster 3 & 300
For Toro Greensmaster 3000 see pages 828-833
For Toro Greensmaster 3100 see pages 844-849
