813
Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
Crankshaft - Group 8
1 RKX26934 X-269-34 Kohler Retainer 2 0.73
2 RK4704201 47 042 01 Use RK4504303
2 RK4504303 45 043 03 Kohler Gear Assy. 2 65.45
3 RK4703001 47 030 01 Kohler Bearing, Needle 2 8.75
4 RK4775501 47 755 01 Kohler Kit, Spacer 1 22.75
5 RK4501405 45 014 05 Use RK4514236
5 RK4514217 45 142 17 Use RK4514236
5 RK4514236 45 142 36 Kohler Crankshaft 1 244.20
Cylinder Head - Group 9
1 RK4744501 47 445 01 Use RK4744502
1 RK4744502 47 445 02 Kohler Strap, Lifting 1 2.05
2 RK237658 237658 Use RK4704110
2 RK4704110 47 041 10 Use RK4704115
2 RK4704115 47 041 15 Kohler Gasket, Cylinder Head 1 9.35
3 RK237670 237670 Kohler Head, Cylinder 1 113.25
4 RK270158 270158 Kohler Screw, H.C. 3/8-16 x 1 1/2 8 2.70
5 RK270721 270721 Kohler Screw, H.C. 3/8-16X1 3/4 1 3.65
6 RK270889 270889 Kohler Washer, Plain 3/8 10 2.70
Dipstick - Group 10
1 RK237012 237012 Use RK4712308
1 RK4712308 47 123 08 Kohler Tube, Oil Fill 1 21.05
2 RK237013 237013 Kohler Dipstick 1 13.30
Electric Start - Group 11
1 RKX221 X-22-1 Kohler Washer 3/8 2 0.99
2 RK234948 234948 Kohler Screw, H.C. 3/8-16 x 1-11/32 2 3.00
3 RK4509807 45 098 07 Use RK4509809
3 RK4509809 45 098 09 Kohler Starter Assy 1 139.85
4 RK4175533 47 755 07 Kohler Kit, Drive 1 77.65
5 RK4775515 47 755 15 Kohler Kit, Drive Parts 1 23.65
6 RK4508105 237650 Kohler Cap, Drive End 1 40.30
8 RK4822704 48 227 04 Discontinued 1
9 RK237649 237649 Kohler Thru Bolt with Washer 2 9.50
10 RK4875515 48 755 15 Use RK5275515
10 RK8275528 52 755 15 Kohler Kit, Brush 1 34.80
RK5235701 52 357 01 Kohler Lubricant, Starter 1 4.15
1
5
2
4
1
2
3
4
5
6
8
9
10
1
2
3
1
2
3
4
6
6
5
Model K321S Spec. 60407
Fits Toro Greensmaster 3 & 300
For Toro Greensmaster 3000 see pages 828-833
For Toro Greensmaster 3100 see pages 844-849
