All original equipment manufacturers names and part numbers are used for identification purposes only, and we
are in no way implying that our products are original equipment parts. Prices subject to change without notice.
Order Factory Direct 800-528-3446
Fax 520-294-1045 • www.rrproducts.com
Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
Model M16QS Spec. 711563
Fits Toro Reelmaster 216
12
11
2
8
10
4
14
13
7
6
9
3
18
11
5
17
16
15
1
5
2
4
3
1
4
5
1 10
7
2
9
8
6
3
16
11
12
131514
18
17
19
Carburetor - Group 5
1 RKX7701 X-770-1 Kohler Screw, Sltd. Hd. 2 1.30
2 RK4704901 47 049 01 Kohler Gasket, Carburetor 1 7.45
3 RK4515501 45 155 01 Kohler Connector, Hose 1 3.35
4 RK4585313 45 053 76 Kohler Carburetor Assy. 1 187.15
5 RK232555 232555 Kohler Spring, Idle Speed 1 3.50
6 RK232556 232556 Kohler Screw, Idle Speed Adjusting 1 2.70
7 RK200372 200372 Kohler Gasket, Bowl Retainer Screw 1 1.00
8 RK4710006 47 100 06 Kohler Screw, Bowl Retainer 1 3.00
9 RK235448 235448 Kohler Bowl 1 7.90
10 RK200376 200376 Kohler Pin 1 2.05
11 RK2575703 25 757 03 Kohler Kit, Float 1 9.25
12 RK2504102 25 041 02 Kohler Gasket, Bowl Baffle 1 2.70
13 RK200383 200383 Kohler Spring, Main Fuel 1 2.10
14 RK275231 275231 Kohler Needle, Idle Fuel Adjusting 1 6.25
15 RK200380 200380 Kohler Spring, Idle Fuel 1 2.70
16 RK200375 200375 Kohler Gasket, Bowl 1 2.60
17 RKX39110 X-391-10 Kohler Connector, Hose 1 6.20
18 RK4510301 45 103 01 Kohler Needle, Main Fuel Adj. 1 12.00
19 RK2575702 25 757 02 Kohler Kit, Carburetor Repair 1 11.50
Crankcase - Group 7
1 RK4713901 47 139 01 Kohler Plug, Hex. Ctsk. 3/4 N.P.T.F 1 2.40
2 RK4704109 47 041 09 Kohler Gasket, Bearing Plate 1 1.55
3 RKX23011 X-230-11 Kohler Plug, Expansion 1 0.47
4 RK4703206 47 032 06 Kohler Seal, Front Oil 1 7.15
5 RK4703207 47 032 07 Kohler Seal, Rear Oil 1 7.15
6 RK235025 235025 Kohler Gasket, Camshaft Cover 1 3.50
7 RK235026 235026 Kohler Cover, Camshaft 1 8.05
8 RK4742205 47 422 05 Kohler Gasket, Shim A/R 1.45
9 RK235125 235125-S Kohler Shaft, Governor Gear 1 28.20
10 RK236559 236559 Kohler Shaft, Balance Gear Stub 2 11.60
11 RK235376 235376 Kohler Bearing, Ball 2 75.45
12 RK4714611 47 146 11 Kohler Plate, Bearing 1 106.05
13 RKX1326 X-132-6 Kohler Screw, H.C. 1/4-20 x 1/2 4 0.81
14 RKX1592 X-159-2 Kohler Screw, H.C. 3/8-16 x 1 4 1.30
15 RK4578233 45 782 23 Kohler Block, Cylinder Miniblock 1 926.15
16 RK230265 230265 Kohler Insert, Valve 2 30.00
17 RK235007 235007-S Kohler Guide, Valve 2 10.05
18 RK234866 234866 Kohler Bearing 1 2.70
Crankshaft - Group 8
1 RK4501486 45 014 86 Kohler Kit, Crankshaft 1 180.75
2 RKX26934 X-269-34 Kohler Retainer 2 0.73
3 RK4504303 45 043 03 Kohler Gear Assy. 2 65.45
4 RK4703001 47 030 01 Kohler Bearing, Needle 2 8.75
5 RK4775501 47 755 01 Kohler Kit, Spacer 1 22.75
6 RK237769 237769 Kohler Spacer 2 3.50
