Kohler Free Freight RKPX60390 - Handbuch (Seite 32)

881
Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
11
9
5
8
7
2
2
4
4
3
12
1
1
10
6
4
1
10
2
6
8
9
7
3
5
11
12
13
6
2
4
2
8
5
1
7
3
9
12
11
10
13
6
7
8
9
4
5
3
1
11
10
2 13
12
Model M16QS Spec. 711563
Fits Toro Reelmaster 216
Air Intake - Group 1
1 RKX229 X-22-9 Kohler Washer, I.T. #10 2 0.99
2 RKX5057 X-50-57 Kohler Screw, Pan Hd. Mach. 2 0.78
3 RKX5037 X-50-37 Kohler Screw, Pan Hd. Mach. 1 0.47
4 RK5209626 52 096 26 Kohler Cover, Air Cleaner 1 94.70
5 RK4508302 45 083 02 Kohler Element 1 9.90
6 RK4508301 45 083 01 Kohler Precleaner, Element 1 5.15
7 RK4704111 47 041 11 Kohler Gasket, Air Horn 1 14.55
8 RKX2579 X-25-79 Kohler Washer, Plain 1 0.99
9 RK5208204 52 082 04 Kohler Cover, Inner 1 9.20
10 RK231032 231032 Kohler Seal 1 2.70
11 RK4875403 48 754 03 Kohler Kit, Air Cleaner Elbow 1 24.50
12 RK5208611 52 086 11 Kohler Screw, Self Tap 1/4-20 x 5/8 1 1.35
13 RK2504106 25 041 06 Kohler Gasket, Air Cleaner Elbow 1 1.10
Baffles & Shroud - Group 2
1 RKX2553 X-25-53 Kohler Washer 1 0.81
2 RK5208611 52 086 11 Kohler Screw, Hex. Wash. Hd. 6 1.35
1/4-20x 5/8
3 RK4708608 47 086 08 Kohler Screw, Pozidriv T.H. 1 1.80
1/4-20 x 5/8
4 RK4706306 47 063 06 Kohler Baffle, Side Air 1 15.70
5 RK4706310 47 063 10 Kohler Baffle, Cylinder 1 9.50
6 RK4702742 47 027 42 Kohler Housing, Blower 1 76.95
7 RK4506308 45 063 08 Kohler Baffle, Head 1 14.25
8 RK4706307 47 063 07 Kohler Baffle, Inner 1 12.70
9 RK4712623 47 126 23 Kohler Bracket, Duct 1 3.65
10 RK4775533 47 755 33 Kohler Kit, Air Duct 1 93.25
11 RKX6764 X-67-64 Kohler Screw, Hex. Wash. Hd. 3 0.83
12 RKX2520 X-25-20 Kohler Washer, Plain 1/4 1 0.99
13 RKX1544 X-154-4 Kohler Screw, H.C. Sems 1 0.99
Breather & Vent - Group 3
1 RK275144 275144 Kohler Gasket, Valve Cover 1 2.60
2 RK4732602 47 326 02 Kohler Hose 1 16.95
3 RKX7991 X-799-1 Kohler Palnut, 1/4-20 1 0.96
4 RK231032 231032 Kohler Seal, Breather 1 2.70
5 RK235047 235047 Kohler Reed, Breather 1 5.90
6 RK235048 235048 Kohler Gasket, Breather Plate 1 2.30
7 RK235117 235117 Kohler Baffle, Breather 1 2.40
8 RK235118 235118 Kohler Filter, Breather 1 5.90
9 RK275220 275220 Kohler Stud, Valve Cover 1 3.65
10 RK235631 235631 Kohler Plate, Breather 1 12.70
11 RK275839 275839 Kohler Cover, Valve 1 37.80
12 RKX4263 X-426-3 Kohler Clamp, Hose 1/2" wide 1 2.80
13 RKX4269 X-426-9 Kohler Clamp, Hose 5/16" wide 1 2.55
Camshaft & Valves - Group 4
1 RK5241301 52 413 01 Kohler Rotator 2 11.45
2 RK235011 235011 Kohler Retainer, Spring Upper 2 2.05
3 RK4175510 41 755 10 Kohler Kit, Retainer 2 4.10
4 RK235168 235168 Kohler Spring, Valve 2 5.90
5 RK4738009 47 380 09 Kohler Pin, Camshaft 1 8.60
6 RKD235327 D-235327 Kohler Tappet 2 19.30
7 RK235582 235582 Kohler Valve, Intake 1 52.45
8 RK237672 237672 Kohler Valve, Exhaust 1 36.80
9 RK275066 275066 Kohler Spacer, Camshaft .005 A/R 2.70
9 RK275067 275067 Kohler Spacer, Camshaft .010 A/R 2.70
10 RK4701011 47 010 11 Kohler Camshaft Assy. 1 78.90
11 RK4708901 47 089 01 Kohler Spring, Actuating 1 3.50
12 RKX7023 X-702-3 Kohler Plug, Cup 1 0.72
