Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
998
Order Factory Direct 800-528-3446
Fax 520-294-1045 • www.rrproducts.com
Carburetor - Group 5
1 RKX7701 X-770-1 Kohler Screw, Sltd. Hd. 2 1.30
2 RK4704901 47 049 01 Kohler Gasket, Carburetor 1 7.45
3 RK2515502 25 155 02 Kohler Connector, 90 0 Hose 1 0.47
4 RK4505370 45 053 70 Use RK4585312
4 RK4585312 45 853 12 Kohler Carburetor Assy. 1 191.45
5 RK232555 232555 Kohler Spring, Idle Speed 1 3.50
6 RK232556 232556 Kohler Screw, Idle Speed Adjusting 1 2.70
7 RK200372 200372 Kohler Gasket, Bowl Retainer Screw 1 1.00
8 RK4710006 47 100 06 Kohler Screw, Bowl Retainer 1 3.00
9 RK235448 235448 Kohler Bowl 1 7.90
10 RK200376 200376 Kohler Pin 1 2.05
11 RK2575703 25 757 03 Kohler Kit, Float 1 9.25
12 RK2504102 25 041 02 Kohler Gasket, Bowl Baffle 1 2.70
13 RK200383 200383 Kohler Spring, Main Fuel 1 2.10
14 RK275231 275231 Kohler Needle, Idle Fuel Adjusting 1 6.25
15 RK200380 200380 Kohler Spring, Idle Fuel 1 2.70
16 RK200375 200375 Kohler Gasket, Bowl 1 2.60
17 RK4704105 47 041 05 Kohler Gasket, Air Cleaner 1 2.10
18 RK4510301 45 103 01 Kohler Needle, Main Fuel Adj. 1 12.00
19 RK2575702 25 757 02 Kohler Kit, Carburetor Repair 1 11.50
Crankcase - Group 7
1 RK4713901 47 139 01 Kohler Plug, Hex. Ctsk. 3/4 N.P.T.F 1 2.40
2 RK4704109 47 041 09 Kohler Gasket, Bearing Plate 1 1.55
3 RKX23011 X-230-11 Kohler Plug, Expansion 1 0.47
4 RK4703206 47 032 06 Kohler Seal, Front Oil 1 7.15
5 RK4703207 47 032 07 Kohler Seal, Rear Oil 1 7.15
6 RK235025 235025 Kohler Gasket, Camshaft Cover 1 3.50
7 RK235026 235026 Kohler Cover, Camshaft 1 8.05
8 RK4742205 47 422 05 Kohler Gasket, Shim A/R 1.45
9 RK235125 235125-S Kohler Shaft, Governor Gear 1 28.20
10 RK236559 236559 Kohler Shaft, Balance Gear Stub 2 11.60
11 RK235376 235376 Kohler Bearing, Ball 2 75.45
12 RK4714611 47 146 11 Kohler Plate, Bearing 1 106.05
13 RKX1326 X-132-6 Kohler Screw, H.C. 1/4-20 x 1/2 4 0.81
14 RKX1592 X-159-2 Kohler Screw, H.C. 3/8-16 x 1 4 1.30
15 RK4578223 45 782 23 Kohler Block, Cylinder Miniblock 1 1,064.15
16 RK230265 230265 Kohler Insert, Valve 2 30.00
17 RK235007 235007-S Kohler Guide, Valve 2 10.05
18 RK234866 234866 Kohler Bearing 1 2.70
Crankshaft - Group 8
1 RK4514221 45 142 21 Kohler Kit, Crankshaft 1 253.65
2 RKX26934 X-269-34 Kohler Retainer 2 0.73
3 RK4504303 45 043 03 Kohler Gear Assy. 2 65.45
4 RK4703001 47 030 01 Kohler Bearing, Needle 2 8.75
5 RK4775501 47 755 01 Kohler Kit, Spacer 1 22.75
Model M16S Spec. 711559
Fits Toro Greens Aerator
12
11
2
8
10
4
14
13
7
6
9
3
18
11
5
16
17
15
1
5
2
4
3
1
4
5
1 10
7
2
9
8
6
3
16
11
12
131514
18
17
19 20
