Kohler Free Freight RKPX60390 - Handbuch (Seite 38)

Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
947
Air Intake - Group 1
1 RK2504106 2504106 Kohler Gasket 1 1.10
2 RK277116 277116 Kohler Brace, Elbow 1 8.70
3 RK4875402 48 754 02 Kohler Kit, Elbow 1 30.05
4 RK4852901 48 529 01 Kohler Support, Air Cleaner 1 60.35
RK4815504 48 155 04 Kohler Connector 1 4.65
Baffles & Shroud - Group 2
1 RK243035 243035 Kohler Grommet 1 3.00
2 RK277058 277058 Kohler Baffle, Blower Hsg. Support 1 27.80
3 RK4802711 48 027 04 Kohler Housing, Blower 1 124.20
4 RK4806308 48 063 08 Kohler Baffle, Side Cylinder #1 1 47.60
5 RK4806309 48 063 09 Kohler Baffle, Side Cylinder #2 1 53.60
6 RK4806310 48 063 10 Kohler Baffle, Bottom Cylinder #1 1 86.45
7 RK4806312 48 063 12 Kohler Baffle, Top Cylinder #1 1 93.55
8 RK4806302 48 063 02 Kohler Baffle, Top Cylinder #2 1 100.50
9 RK4806313 48 063 13 Kohler Baffle, Bottom Cylinder #2 1 82.35
Breather & Vent - Group 3
1 RKX4263 X-426-3 Kohler Clamp, Hose 1 2.80
2 RK220368 220368 Kohler Stud, Valve Cover 1 3.00
3 RK270034 270034 Kohler Gasket, Valve Cover 1 3.00
4 RK270036 270036 Kohler Cover, Valve 1 11.15
5 RK277392 277392 Kohler Hose, Breather 1 14.25
Camshaft & Valves - Group 4
1 RKX431 X-43-1 Kohler Key, Woodruff 1 0.99
2 RK4810004 48 100 04 Kohler Nut, Jam 1 5.00
3 RK230011 230011 Kohler Retainer, Valve Spring Exh. 2 3.00
4 RK5241301 52 413 01 Kohler Rotator, Exhaust Valve 2 11.45
5 RK235008 235008 Kohler Valve, Intake 2 26.05
6 RK235010 235010 Kohler Spring, Valve Intake 2 5.90
7 RK235011 235011 Kohler Retainer, Valve Spring 4 2.05
8 RK235168 235168 Kohler Spring, Exhaust Valve 2 5.90
9 RK237672 237672 Kohler Valve, Exhaust 2 36.80
10 RK4175510 41 755 10 Kohler Kit, Retainer 4 4.10
11 RK4875534 48 755 34 Kohler Kit, Gear-Camshaft 1 36.85
12 RKD277031 D-277031 Kohler Tappet 4 25.50
13 RK4801201 48 012 01 Kohler Camshaft Assy. 1 196.55
14 RK4846804 48 468 04 Kohler Washer 1 3.45
3
1
2
3
4
5
1
2
3
4
9
6
7
8
5
4
1
2
3
3
14
5
6
7
8
9
10
11
12
1
13
2
14
Model K582QS Spec. 36315
Fits Toro Turf Pro
