Kohler Free Freight RKPX60390 - Handbuch (Seite 41)

Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
950
All original equipment manufacturers names and part numbers are used for identification purposes only, and we
are in no way implying that our products are original equipment parts. Prices subject to change without notice.
Order Factory Direct 800-528-3446
Fax 520-294-1045 • www.rrproducts.com
1
2
3
4
5
6
8
9
10
11
12
13
14
15
16
17
18
1
2
3
4
5
6 7
8
9
10
11
12
13
19
20
21
22
24
25
26
27 28
29 30
31
32
33
34
35
36
38
41
43
40
39
23
37
42
Model K582QS Spec. 36315
Fits Toro Turf Pro
Governor - Group 17
1 RK2513960 X-75-23 Kohler Plug 1 1.00
2 RK277078 277078 Kohler Gasket, Governor Housing 1 2.80
3 RK271151 271151 Kohler Rod, Throttle 1 3.80
4 RK4520803 45 208 03 Kohler Body, Ball Joint 1 6.40
5 RKX4898 X-489-8 Kohler Rod, Breaker Push 1 2.15
6 RK5204111 52 041 11 Kohler Gasket, Breaker Cover 1 1.00
7 RK220074 220074 Kohler Diaphragm 1 3.00
8 RK232535 232535 Kohler Cover, Breaker 1 6.40
9 RK271547 271547 Kohler Spring, Governor 1 11.15
10 RK275691 275691 Kohler Screw, Shoulder 1 5.90
11 RK277073 277073 Kohler Gasket 1 2.30
12 RK277080 277080 Kohler Lever, Throttle 1 12.60
13 RKA277905 A-277905 Kohler Housing, Breather 1 24.70
14 RK277341 277341 Kohler Washer, Tension 1 2.40
15 RK4815003 48 150 03 Kohler Breaker 1 20.20
16 RK4819401 48 194 01 Kohler Joint, Ball 1 4.10
17 RK4875510 48 755 10 Kohler Kit, Clamp 1 7.45
18 RK4831028 48 310 28 Kohler Governor Assy. 1 434.65
19 RKX26915 X-269-15 Kohler Ring, Retaining 1 0.99
20 RKX2932 X-293-2 Kohler Bearing, Needle 1 9.00
21 RKX2933 X-293-3 Kohler Bearing, Needle 1 8.25
22 RK4803002 48 030 02 Kohler Bearing, Needle 1 16.30
23 RK237022 237022 Kohler Washer 1 2.40
24 RK240202 240202 Kohler Bearing, Ball 1 34.30
25 RK275055 275055 Kohler Seal, Oil 1 11.15
26 RK277099 277099 Kohler Gasket, Governor Cover 1 2.70
27 RK277100 277100 Kohler Bearing, Roller Thrust 1 8.85
28 RK277101 277101 Kohler Race, Thrust Bearing 1 3.50
29 RK277102 277102 Kohler Race, Thrust Bearing 1 5.10
30 RK277104 277104 Kohler Ring, Retaining 1 2.05
31 RK4804311 277561 Kohler Gear, Governor 1 21.90
32 RK4808102 48 081 02 Kohler Housing 1 101.50
33 RK4809605 48 096 05 Kohler Cover, Governor 1 92.95
34 RK4875501 48 755 01 Kohler Kit, Sleeve 1 14.70
35 RK4847102 48 471 02 Kohler Yoke, Governor 1 3.00
36 RK4808703 48 087 03 Kohler Lever, Governor 1 59.35
37 RK4842008 48 420 08 Kohler Shaft, Governor Assy. 1 308.35
38 RKX2694 X-269-4 Kohler Ring, Retaining 1 0.99
39 RK230080 230080 Kohler Pin, Flyweight 2 3.50
40 RK277007 277007 Kohler Shaft, Governor 1 71.05
41 RK277114 277114 Kohler Flyweights 2 6.60
42 RK4808901 48 089 01 Kohler Spring 2 2.70
43 RKX2808 X-280-8 Kohler Pin, Roll 1 0.99
Ignition - Group 18
1 RK210281 210281 Kohler Clip, Cable 2 2.40
2 RK230722 230722 Kohler Condensor 1 5.00
3 RK235041S 235041-S Kohler Plug, Spark 2 4.55
4 RK236602 236602 Kohler Connector 1 3.30
5 RK4815502 48 155 02 Kohler Connector 1 4.35
6 RK271694 271694 Kohler Plate, Coil Mounting 1 5.00
7 RK277375 277375 Kohler Coil 1 140.85
8 RK2575503 25 755 03 Kohler Kit, Rectifier, Regulator 1 56.95
9 RK237878 237878 Kohler Kit, Stator 1 76.10
10 RK4834803 48 348 08 Kohler Lead, Hi-Tension 1 15.30
11 RK4834804 48 348 04 Kohler Lead, Hi-Tension 1 12.60
12 RK4808801 48 088 01 Kohler Bracket, Coil 1 27.35
13 RK2551808 25 518 08 Kohler Lead, 14 Ga. 11" 1 4.40
14 RK2551813 25 518 13 Kohler Lead, 14 Ga. 9" 1 2.70
