Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
983
Air Intake - Group 1
1 RK4504107 45 041 07 Kohler Gasket, Air Horn 1 2.05
Baffles & Shroud - Group 2
1 RKX2553 X-25-53 Kohler Washer 1 0.81
2 RKX1322 X-132-2 Kohler Screw, H.C. 1/4-20 x 3/4 5 0.99
3 RKX1326 X-132-6 Kohler Screw, H.C. 1/4-20 x 1/2 2 0.81
4 RK235652 235652 Kohler Baffle, Side Air 1 6.60
5 RK4702718 47 027 18 Kohler Housing, Blower 1 104.05
6 RK237677 237677 Kohler Baffle, Head 1 15.30
7 RK236676 236676 Kohler Baffle, Cylinder 1 8.05
Breather & Vent - Group 3
1 RKX4263 X-426-3 Kohler Clamp, Hose 1 2.80
2 RKX4269 X-426-9 Kohler Clamp, Hose 1 2.55
3 RK231032 231032 Kohler Seal, Breather 1 2.70
4 RK235047 235047 Kohler Reed, Breather 1 5.90
5 RK235048 235048 Kohler Gasket, Breather Plate 1 2.30
6 RK235117 235117 Kohler Baffle, Breather 1 2.40
7 RK235118 235118 Kohler Filter, Breather 1 5.90
8 RK275220 275220 Kohler Stud, Valve Cover 1 3.65
9 RK235631 235631 Kohler Plate, Breather 1 12.70
10 RK275839 275839 Kohler Cover, Valve 1 37.80
11 RK275144 275144 Kohler Gasket 1 2.60
12 RKX7991 X-799-1 Kohler Palnut 1/4-20 1 0.96
13 RK4732602 47 326 02 Kohler Hose 1 16.95
Camshaft & Valves - Group 4
1 RK5241301 52 413 01 Kohler Rotator 2 11.45
2 RK235011 235011 Kohler Retainer, Spring Upper 2 2.05
3 RK235168 235168 Kohler Spring, Valve 2 5.90
4 RK235193 235193 Use RK4738009
4 RK4738009 47 380 09 Kohler Pin, Camshaft 1 8.60
5 RKD235327 D-235327 Kohler Tappet 2 19.30
6 RK235582 235582 Kohler Valve, Intake 1 52.45
7 RK237672 237672 Kohler Valve, Exhaust 1 36.80
8 RK4175510 41 755 10 Kohler Kit, Retainer 2 4.10
9 RK275066 275066 Kohler Spacer, Camshaft .005 (A.R.) 1 2.70
9 RK275067 275067 Kohler Spacer, Camshaft .010 (A.R.) 1 2.70
10 RK4701009 47 010 09 Kohler Camshaft Assy. 1 94.25
11 RK4708901 47 089 01 Kohler Spring, Actuating 1 3.50
1
5
10
9
4
8
6
7
2
3
1
3
2
11
1
3
6
7
8
10
11
9
4
5
1
2
12
13
1
2
3
4
6
7
5
Model K321S Spec. 60434
Fits Toro Sand Pro
