Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
523
Carburetor - Group 5
1 RKX3911 X-391-1 Use RK2515502
1 RK2515502 25 155 02 Kohler Connector 1 0.47
2 RK200380 200380 Kohler Spring, Idle Fuel 1 2.70
3 RKX7701 X-770-1 Kohler Screw, Sltd. Hd. 2 1.30
4 RKA236919 A-236919 Kohler Bracket Assy., Choke 1 7.30
5 RK235603 235603 Kohler Clip, Choke Cable 1 2.05
For Engines Built Before Serial Number
1735210504 Use The Following Parts:
6 RK271030 271030 Kohler Gasket, Carburetor 1 2.30
7 RK4705315 47 053 15 Use RK4785330
7 RK4785330 47 853 30 Kohler Carburetor Assy. 1 195.65
8 RK232555 232555 Kohler Spring, Idle Speed 1 3.50
9 RK232556 232556 Kohler Screw, Idle Speed Adjusting 1 2.70
10 RK200372 200372 Kohler Gasket, Bowl Retainer Screw 1 1.00
11 RK235447 235447 Use RK4710006
11 RK4710006 47 100 06 Kohler Nut, Bowl Retainer 1 3.00
12 RK235448 235448 Kohler Bowl 1 7.90
13 RK237130 45 208 03 Kohler Ball, Joint 1 9.05
14 RK200376 200376 Kohler Pin 1 2.05
15 RK200375 200375 Kohler Gasket, Bowl 1 2.60
16 RK200408 200408 Use RK2575703
16 RK2575703 25 757 03 Kohler Kit, Float Repair, Incl. #19 1 9.25
17 RK4710301 47 103 01 Kohler Needle, Main Fuel Adjusting 1 10.85
18 RK200383 200383 Kohler Spring, Idle Fuel Adjusting 1 2.10
19 RK200439 200439 Use RK2504102
19 RK2504102 25 041 02 Kohler Gasket, Anti-splash 1 2.70
20 RK235277 235277 Kohler Rod, Ball Joint 1 7.90
21 RK231555 231555 Use RK2575701
21 RK2575701 25 757 01 Kohler Kit, Repair 1 11.50
22 RK275231 275231 Kohler Needle, Idle Fuel Adj. 1 6.25
23 RKX703 X-70-3 Kohler Nut, Hex 1 0.83
For Engines Built After Serial Number
1735210494 Use The Following Parts:
25 RK4785330 47 853 30 Kohler Kit, Carburetor w/Linkage 1 195.65
26 RK271030 271030 Kohler Gasket, Carburetor 1 2.30
27 RK4704901 47 049 01 Kohler Gasket, Carburetor 1 7.45
28 RK4707911 47 079 11 Kohler Linkage, Carburetor 1 1.25
29 RK2515807 25 158 07 Use RK2515811
29 RK2515811 25 158 11 Kohler Bushing, Yellow, Linkage Retaining 1 1.00
30 RK275341 275341 Kohler Gasket, Air Cleaner 4 2.05
31 RK2508627 25 086 27 Kohler Screw, Throttle & Choke Plate 1 1.45
32 RK4714609 47 146 09 Kohler Plate, Choke 1 2.30
33 RK2519401 25 194 01 Kohler Ball, Choke Friction 1 4.40
34 RK2508903 25 089 03 Kohler Spring, Choke Friction 1 4.40
35 RK4714436 47 144 25 Kohler Shaft, Throttle w/Lever & Seal 1 12.55
36 RK4714610 47 146 10 Kohler Plate, Throttle 1 5.90
37 RK2508902 25 089 02 Kohler Spring, Idle Fuel 1 1.85
38 RK2536801 25 368 01 Kohler Needle, Idle Fuel Adj. 1 2.35
39 RK2508904 25 089 04 Kohler Spring, Idle Speed 1 3.85
40 RK2508626 25 086 26 Kohler Screw, Idle Speed Adj. 1 1.80
41 RK4709038 47 090 38 Kohler Lever, Choke 1 17.65
42 RK5233708 52 337 08 Kohler Jet, Main 1 4.15
43 RK2504104 25 041 04 Kohler Gasket, Bowl 1 3.15
44 RK2575709 25 757 09 Kohler Kit, Float 1 11.30
45 RK2510401 25 104 01 Kohler Bowl, Fuel 1 9.15
46 RK2504103 25 041 03 Kohler Gasket, Bowl Retainer Screw 1 2.40
47 RK2510005 25 100 05 Kohler Screw, Bowl Retainer 1 1.60
RK2575711 25 757 11 Kohler Kit, Carburetor Repair 1 25.15
RK4775538 47 755 38 Kohler Kit, High AltitudeJet 1 9.90
6
12
14
11
8
15
17
16
5
4
13
2
3
9
1
7
10
19
18
20
22
23
21 24
25
26
27
28
29
29
31
32
33
34
35
36
37
38
39 40
41
42
43
44
45
46
47
30
Model K321S Spec. 60390
Fits Jacobsen Greens King II
