Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
Ignition - Group 18
1 RK4758403 47 584 03 Kohler Module, Ignition 1 50.75
2 RKX6751 X-156-1 Kohler Screw, H.C. Sems 2 0.94
3 RKX2579 X-25-79 Kohler Washer, Plain #10 2 0.99
4 RK210281 210281 Kohler Clip, High Tension Lead 1 2.40
5 RKX1326 X-132-6 Kohler Screw, R.H. 4 0.81
6 RK235173 235173 Kohler Clip 1 3.65
7 RKX6759 X-67-59 Kohler Screw, Sheet Metal 1 0.39
8 RK235041S 235041-S Kohler Plug, Spark 1 4.55
9 RK2575503 25 755 03 Kohler Rectifier-Regulator 1 56.95
10 RKX1325 X-132-5 Kohler Screw, H.C. Sems 2 0.99
11 RK236602 236602 Kohler Connector, Female 1 3.30
12 RK4115503 41 155 03 Kohler Connector, Male 1 1.00
13 RK237878 237878 Kohler Kit, Stator 1 76.10
14 RK4751846 47 518 46 Kohler Lead, Violet, Rectifier- 1 3.50
14 RK4751843 47 518 43 Kohler Lead, White, Module 1 19.15
Oil Pan - Group 21
1 RK2513956 X-75-6 Kohler Plug, 3/4 1 1.45
2 RKX1593 X-159-3 Kohler Screw, H.C. 3/8-16 x 1 1/4 4 1.30
3 RK235057 235057 Kohler Gasket, Pan 1 3.50
4 RK4719910 47 199 10 Kohler Base, Oil Pan 1 134.25
Piston & Rod - Group 22
OLD STYLE PISTON
1 RK4506724 45 067 22 Kohler Rod, Connecting - Standard 1 59.85
1 RK4506725 45 067 23 Kohler Rod, Connecting - .010 1 83.55
2 RK4587401 45 874 01 Kohler Piston Assy, Standard 1 154.70
2 RK4587402 45 874 02 Kohler Piston Assy, .003 1 164.90
2 RK4587403 45 874 03 Kohler Piston Assy, .010 1 154.70
2 RK4587404 45 874 04 Kohler Piston Assy, .020 1 120.35
2 RK4587405 45 874 05 Kohler Piston Assy, .030 1 120.35
3 RK4510810 45 108 06 Kohler Ring Set, Std. & .003 1 59.25
3 RK4510811 45 108 07 Kohler Ring Set, .010 1 73.05
3 RK4510812 45 108 08 Kohler Ring Set, .020 1 56.90
3 RK4510813 45 108 09 Kohler Ring Set, .030 1 56.90
4 RK4701801 47 018 01 Kohler Retainer, Pin 2 2.10
NEW STYLE MAHLE PISTON
5 RK4506724 45 067 22 Kohler Rod, Connecting - Standard 1 59.85
5 RK4506725 45 067 23 Kohler Rod, Connecting - .010 1 83.55
6 RK4587411 45 874 01 Kohler Piston Assy, Standard 1 175.00
6 RK4587412 45 874 02 Kohler Piston Assy, .003 1 131.20
6 RK4587413 45 874 03 Kohler Piston Assy, .010 1 168.90
6 RK4587414 45 874 04 Kohler Piston Assy, .020 1 168.70
6 RK4587415 45 874 05 Kohler Piston Assy, .030 1 131.20
7 RK4510810 45 108 06 Kohler Ring Set, Std. & .003 1 59.25
7 RK4510811 45 108 07 Kohler Ring Set, .010 1 73.05
7 RK4510812 45 108 08 Kohler Ring Set, .020 1 56.90
7 RK4510813 45 108 09 Kohler Ring Set, .030 1 56.90
4 RK4701801 47 018 01 Kohler Retainer, Pin 2 2.10
3
2
4
12
7
6
8
10
11
4
1
2
3
9
13
14
1
5
2
3
1
4
OLD STYLE
PISTON
NEW STYLE
PISTON
4
5
7
6
Model M16QS Spec. 711563
Fits Toro Reelmaster 216
