Kohler Free Freight RKPX60390 - Handbuch (Seite 5)

Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
525
Electric Start - Group 11
1 RKX221 X-22-1 Kohler Washer 3/8 2 0.99
2 RK234948 234948 Kohler Screw, H.C. 3/8-16 x 1 11/32 2 3.00
3 RKA237534 A-237534 Use RK4509809
3 RK4509809 45 098 09 Kohler Starter Assy 1 139.85
4 RK4575515 45 755 15 Kohler Kit, Drive 1 79.25
5 RK4575515 45 755 15 Kohler Kit, Drive Parts 1 79.25
6 RK4508105 45 081 05 Kohler Cap, Drive End 1 40.30
7 RK4717001 47 170 01 Kohler Armature 1 158.25
8 RK4822704 48 227 04 Discontinued 1
9 RK237649 237649 Kohler Thru Bolt with Washer 2 9.50
10 RK4875515 48 755 15 Use RK8275528
10 RK8275528 82 755 28 Kohler Kit, Brush 1 34.80
Flywheel - Group 13
1 RK4702528 47 025 28 Kohler Flywheel 1 282.05
Before Serial Number 1525200013 Use:
2 RKX25104 X-25-104 Kohler Washer 5/8 1 0.91
3 RKX11914 X-119-14 Use RK2510002
3 RK2510002 25 100 02 Kohler Nut, Lock 5/8-18 1 1.25
4 RKX28617 X-286-17 Kohler Key 1 0.73
After Serial Number 1525200003 Use:
5 RKX463 X-46-3 Kohler Key, Woodruff 1 0.93
6 RK5246815 52 468 15 Kohler Washer, plain 1 3/8 O.D. 1 2.05
7 RK2508624 25 086 24 Kohler Screw, hex. mach. 3/8-24x1 1/8 1 1.25
Fuel Pump - Group 14
1 RKX1742 X-174-2 Kohler Screw, F.H.M. 1/4-20 x 3/4 2 0.47
2 RK4704104 47 041 04 Use RK2504109
2 RK2504109 25 041 09 Kohler Gasket, Fuel Pump 1 1.15
3 RK240282 240282 Kohler Cover, Pump Pad 1 3.35
Governor - Group 17
1 RKX7991 X-799-1 Kohler Palnut, 1/4-20 1 0.96
2 RKX40080 X-400-80 Kohler Spacer 1 0.83
3 RK231355 231355 Kohler Pin, Governor Stop 1 3.35
4 RKX7761 X-776-1 Kohler Screw, sems 1/4-20 x 1 1/4 1 1.30
5 RK235476 235476 Kohler Bushing 1 4.90
6 RK236261 236261 Kohler Spring, Governor 1 6.25
7 RK237022 237022 Kohler Washer, Thrust 1 2.40
8 RKA237031 237031 Use RKA253743S
8 RKA235743 A-235743-S Kohler Kit, Governor Gear 1 22.10
9 RK237455 237455 Use RKA235256
9 R KA235256 A-235256-S Kohler Shaft, Governor 1 9.15
10 RKX2563 X-25-63 Kohler Washer, Plain 17/64 1 0.93
11 RKX1329 X-132-9 Kohler Screw, sems 1/4-20 x 1 1/4 1 0.99
12 RK236413 236413 Kohler Bracket, Speed Control 1 5.10
13 RK236415 236415 Kohler Spacer 1 6.20
14 RK237573 237573 Kohler Spring 1 7.55
15 RK237574 237574 Kohler Screw, Adjusting 1 2.70
16 RK237833 237833 Kohler Lever, Adjusting Screw 1 10.65
17 RK275690 275690 Kohler Washer, Wave 1 2.10
18 RKA237653 A-237653 Kohler Lever Assy., Governor 1 22.30
19 RK2546801 25 468 01 Kohler Washer, Plain 1/4 1 1.00
Before Serial Number 1735210504 Use:
21 RK235278 235278 Kohler Retainer, Rod 1 2.05
After Serial Number 1735210494 Use:
22 RK4715806 47 158 06 Use RK2515811
22 RK2515811 25 158 07 Kohler Bushing, Yellow, Linkage Retaining 2 1.00
23 RK4707911 47 079 11 Kohler Linkage, Governor 1 1.25
3
4
5
6
7
8
9
10
1
2
7
6
5
3
2
1
4
2
1
3
2
5
21
3
9
12
13
14
15
16
8
7
6
18
4
22
10
11
17
1
19
23
22
Model K321S Spec. 60390
Fits Jacobsen Greens King II
