Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
526
Order Factory Direct 800-528-3446
Fax 520-294-1045 • www.rrproducts.com
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
18
19
22
23
24
20 21
1
3
4
2
4
3
2
1
16
OLD STYLE
PISTON
7
3
6
5
NEW STYLE
PISTON
Model K321S Spec. 60390
Fits Jacobsen Greens King II
Ignition - Group 18
1 RKX2573 X-25-73 Kohler Washer 1/4 2 0.99
2 RKX6759 X-67-59 Kohler Screw, Sheet Metal 1 0.39
3 RKX1311 X-131-1 Kohler Screw, F.H.M. 10-24 x 3/8 4 0.47
4 RKX1322 X-132-2 Kohler Screw, H.C. 1/4-20 1 0.99
5 RKX4897 X-489-7 Use RK4741104
5 RK4741104 47 411 04 Kohler Rod, Breaker 1 8.20
6 RKX7281 X-728-1 Kohler Clip 1 0.93
7 RKX7781 X-778-1 Use RKX6751
7 RKX6751 X-675-1 Kohler Screw, R.H. 1 0.94
8 RK220174 220174 Use RK5204111
8 RK5204111 52 041 11 Kohler Gasket, Breaker 1 1.00
9 RK232535 232535 Kohler Cover, Breaker 1 6.40
10 RK234323 234323 Kohler Plate, Coil 1 5.00
11 RK235040S 235040-S Use RK235041S
11 RK235041 235041-S Kohler Plug, Spark 1 4.55
12 RK238057 238057 Kohler Kit, High Tension Lead 1 20.70
13 RK275303 275303 Kohler Clip 1 2.05
14 RK237878 237878 Kohler Stator 1 76.10
15 RK4715001 47 150 01 Use RK4715003
15 RK4715003 47 150 03 Kohler Point Set 1 10.10
16 RK230722 230722 Kohler Condenser 1 5.00
17 RK231281 231281 Kohler Coil 1 29.95
18 RK4140306 41 403 06 Kohler Regulator 1 93.15
19 RKA237418 237418 Kohler Lead, Black, Breaker To Coil 1 5.35
20 RK4775703 47 757 03 Kohler Tune Up Kit 1 22.40
21 RK4775705 47 757 05 Kohler Ignition Kit 1 17.15
22 RK220297 220297 Grommet 1 2.05
23 RKX2565 X-25-65 Washer, Plain #8 2 0.99
24 RKX1415 X-14-15 Screw, R.H.M. 8-32 x 1/4 2 0.99
Oil Pan - Group 21
1 RKX7510 X-75-10 Kohler Plug, Pipe 3/8 1 2.10
2 RKX1593 X-159-3 Kohler Screw, H.C. 3/8-16 x 1 1/4 4 1.30
3 RK235057 235057 Kohler Gasket, Pan 1 3.50
4 RK235147 235147 Kohler Base, Oil Pan 1 126.40
Piston & Rod - Group 22
OLD STYLE PISTON DESIGN
1 RK4706709 47 067 09 Kohler Rod, Connecting - Standard 1 45.10
1 RK4706710 47 067 10 Kohler Rod, Connecting - .010 1 45.10
2 RK4787411 47 874 11 Kohler Piston Assy, Standard 1 131.90
2 RK4787412 47 874 12 Kohler Piston Assy, .003 1 111.55
2 RK4787413 47 874 13 Kohler Piston Assy, .010 1 131.90
2 RK4787414 47 874 14 Kohler Piston Assy, .020 1 131.90
2 RK4787415 47 874 15 Kohler Piston Assy, .030 1 131.90
3 RK4810805 48 108 05 Kohler Ring Set, Std. & .003 1 53.90
3 RK4810806 48 108 06 Kohler Ring Set, .010 1 49.40
3 RK4810807 48 108 07 Kohler Ring Set, .020 1 63.50
3 RK4810808 48 108 08 Kohler Ring Set, .030 1 63.50
4 RK4701801 47 018 01 Kohler Retainer, Pin 1 2.10
NEW STYLE MAHLE PISTON DESIGN
5 RK4506724 45 067 24 Kohler Rod, Connecting - Standard 59.85
5 RK4506725 45 067 25 Kohler Rod, Connecting - .010 83.55
6 RK4787421 47 874 21 Kohler Piston Assy, Standard 166.65
6 RK4787422 47 874 22 Kohler Piston Assy, .003 124.95
6 RK4787423 47 874 23 Kohler Piston Assy, .010 160.65
6 RK4787424 47 874 24 Kohler Piston Assy, .020 160.65
6 RK4787425 47 874 25 Kohler Piston Assy, .030 124.95
7 RK4710805 47 108 05 Kohler Ring Set, Std. & .003 59.30
7 RK4710806 47 108 06 Kohler Ring Set, .010 56.55
7 RK4710807 47 108 07 Kohler Ring Set, .020 56.55
7 RK4710808 47 108 08 Kohler Ring Set, .030 56.55
4 RK4701801 47 018 01 Kohler Retainer, Pin 2.10
Order parts according to design used on engine
