814
Item R&R
KOHLER
Qty. Discounted
No.
Part No.
Part No. Description
Req. Price Each
Exhaust - Group 12
1
RK235899
235899
Use RK4107219
1
RK4107219 47 072 19 Kohler Stud
2
3.10
2
RK235122
235122
Kohler Gasket, Exhaust Flange 2
2.70
Flywheel - Group 13
1
RK4702524 47 025 24 Kohler Flywheel
1
339.20
2
RK4775515 47 755 15 Kohler Kit, Grass Screen
1
23.65
3
RK4708608 47 086 08 Kohler Screw,
pozidriv T.H. 1/4-20x5/8
4
1.80
4
RKX28617
X-286-17 Kohler Key, Square
1
0.73
Before Serial #15139547
6
RKX11914
X-119-14 Use RK2510002
6
RK2510002 25 100 02 Kohler Nut, Lock 5/8-18
1
1.25
Before Serial #15139547
7
RKX463
X-46-3
Kohler Key, Woodruff
1
0.93
After Serial #15139546
8
RK5211402 52 114 02 Use RK5246815
8
RK5246815 52 468 15 Kohler Washer, Plain 1 3/8 O.D. 1
2.05
After Serial #15139546
9
RK2508604 25 086 04 Use RK2508624
9
RK2508624 25 086 24 Kohler Screw,
Hex. Mach. 3/8-24x1 1/8
1
1.25
After Serial #15139546
Fuel Pump - Group 14
1
RKX1742
X-174-2
Kohler Screw, F.H.M. 1/4-20 x 3/4 2
0.47
2
RK4704104 47 041 04 Use RK2504105
2
RK2504109 25 041 09 Kohler Gasket, Fuel Pump
1
1.15
3
RK240282
240282
Kohler Cover, Pump Pad
1
3.35
Governor - Group 17
1
RK2546801 25 468 01 Kohler Washer
1
1.00
2
RKX40080
X-400-80 Kohler Spacer
1
0.83
3
RK231355
231355
Kohler Pin, Governor Stop
1
3.35
4
RK235278
235278
Kohler Retainer, Rod
1
2.05
5
RK235476
235476
Kohler Bushing
1
4.90
6
RK235496
235496
Kohler Spring, Governor
1
4.75
7
RK237022
237022
Kohler Washer, Thrust
1
2.40
8
RKA236294
A-236294-S
Kohler Kit, Governor Gear
1
20.30
(Incl. thrust washer)
9
RKA235256
A-235256-S
Kohler Kit, Governor Cross Shaft 1
9.15
(Incl. spacer)
10 RKA237653 A-237653 Kohler Lever, Governor Assy.
1
22.30
11
RKX7761
X-776-1
Kohler Screw, sems 1/4-20 x 1 1/4 1
1.30
12 RKX7991
X-799-1
Kohler Palnut1/4-20
1
0.96
13 RKA236947 A-236947 Kohler Bracket, Speed Control
1
15.20
14 RKX2563
X-25-63
Kohler Washer, Pain 1/4
1
0.93
15 RKX25102
X-25-102 Kohler Washer, Plain 1/4
1
0.97
16 RK4108620 X-51-8
Kohler Screw, R.H.M. 8-32 x 1/4 1
1.00
17 RKX1329
X-132-9
Kohler Screw,
H.C. Sems 1/4-20x1 1/4
1
0.99
18 RK4875510 47 755 10 Kohler Kit, Clamp
1
7.45
19 RK235084
235084
Kohler Bracket, Adjusting Screw 1
3.65
20 RK235085
235085
Kohler Spacer
1
3.65
21 RK236249
236249
Kohler Bracket, Speed Control
1
3.35
22 RK275690
275690
Kohler Washer, Tension
1
2.10
1
2
3
1
2
2
4
5
6
9
3
1
12
10
11
19
16 14
15
22
21
17
18
20
13
4
1
3
2
5
6
7
8
9
8
7
Model K321S Spec. 60407
Fits Toro Greensmaster 3 & 300
For Toro Greensmaster 3000 see pages 828-833
For Toro Greensmaster 3100 see pages 844-849
