Kohler Free Freight RKPX60390 - Handbuch (Seite 15)

723
Carburetor - Group 5
1 RKX3911 X-391-1 Use RK2515502
1 RK2515502 25 155 02 Kohler Elbow, Hose 1 0.47
2 RK200380 200380 Kohler Spring, Idle Fuel 1 2.70
3 RKX7701 X-770-1 Kohler Screw, Sltd. Hd. 2 1.30
5 RK275231 275231 Kohler Needle, Idle Fuel Adj. 1 6.25
6 RK271030 271030 Kohler Gasket, Carburetor 1 2.30
7 RK4785330 47 853 30 Kohler Carburetor Assy. 1 195.65
8 RK232555 232555 Kohler Spring, Idle Speed 1 3.50
9 RK232556 232556 Kohler Screw, Idle Speed Adjusting 1 2.70
10 RK200372 200372 Kohler Gasket, Bowl Retainer Screw 1 1.00
11 RK4710006 47 100 06 Kohler Screw, Bowl Retainer 1 3.00
12 RK235448 235448 Kohler Bowl 1 7.90
13 RK2575701 25 757 01 Kohler Kit, Repair 1 11.50
14 RK200376 200376 Kohler Pin 1 2.05
15 RK200375 200375 Kohler Gasket, Bowl 1 2.60
16 RK2575703 25 757 03 Kohler Kit, Float Repair, Incl. #19 1 9.25
17 RK4510301 47 103 01 Kohler Needle, Main Fuel Adjusting 1 12.00
18 RK200383 200383 Kohler Spring, Idle Fuel Adjusting 1 2.10
19 RK2504102 25 041 02 Kohler Gasket, Anti-splash 1 2.70
Crankcase - Group 7
1 RKX7531 X-75-31 Use RK4713901
1 RK4713901 47 139 01 Kohler Plug, Pipe 1 2.40
2 RKX1326 X-132-6 Kohler Screw, H.C. 1/4-20 x 1/2 4 0.81
3 RKX1592 X-159-2 Kohler Screw, H.C. 3/8-16 x 1 4 1.30
4 RKX23011 X-230-11 Kohler Plug 1 0.47
5 RK4703206 47 032 06 Kohler Seal, Front Oil 1 7.15
6 RK4703207 47 032 07 Kohler Seal, Rear Oil 1 7.15
7 RK235025 235025 Kohler Gasket, Cover 1 3.50
8 RK235026 235026 Kohler Cover, Camshaft 1 8.05
9 RK235070 235070 Kohler Gasket A/R 2.40
10 RK235125 235-125-S Kohler Shaft, Governor 1 28.20
11 RK235376 235376 Kohler Bearing, Ball 2 75.45
12 RK235757 235757 Kohler Gasket 2 4.10
13 RK236559 236559 Kohler Shaft 1 11.60
14 RK4515603 45 156 03 Kohler Plate, Bearing 1 109.25
15 RK4778298 47 782 82 Kohler Block, Cylinder Miniblock 1 895.30
16 RK230265 230265 Kohler Insert, intake 2 30.00
17 RK235007 235007-S Kohler Guide, Valve 2 10.05
18 RK234866 234866 Kohler Bearing 1 2.70
19 RKX7023 X-702-3 Kohler Plug, Cup 0.72
6
12
14
11
8
15
17
16
2
3
9
1
7
10
19
18 5
13 4
11
14
5
3
4
6
7
8
10
15
17
18
11
16
9
13
1
2
12
Model K301S Spec. 47827
Fits National Mower
Item R&R KOHLER Qty. Discounted
No. Part No. Part No. Description Req. Price Each
