WARTUNG
HyPerformance HD4070
Betriebsanleitung
5-3
HD4070-Anlagenbeschreibung
Steuer- und Signalkabel
4070.28
Power Cable: Provides 120 VAC to the Gas Console.
Signal Cable: Provides process and status signals
between the Power Supply and the Gas Console.
Power Cable: Provides 120 VAC to the Ignition Console
and control power for the off-valve assembly.
Control Cable: Provides 120 VAC control power
to the solenoid valves.
Netzkabel: Gibt 120 VAC an die Gaskonsole ab.
Signalkabel: Gibt Prozess- und Status-Signale
zwischen Stromquelle und Gaskonsole ab.
Netzkabel: Gibt 120 VAC an die Zündkonsole und
Steuerstrom für die Abschaltventil-Baugruppe ab.
Steuerkabel: Gibt 120 VAC Steuerstrom an
die Magnetventile.
