ERSATZTEILELISTE
1
6-20 HyPerformance HD4070 Betriebsanleitung
Teilnummer Beschreibung
220162 Torch head with no consumables
129568 20 kW chopper with fan
027080 Chopper Cooling Fan
041564 Phase Loss Detection PCB
129264 Pilot arc controller board (Start Circuit Board Assembly)
129566 System I/O board / surge injection
041594 I/O PCB SA
109201 Current Sensor Hall 500A:4V
009015 Resistor: 10K-OHM 10W
003142 Relay:120VAC
009912 Capasitor:35OUF 450WV
109205 Resistor: 20-OHM 50W
009622 Resistor: 10-OHM 50W
009827 Resistor: 100-OHM 50W
109204 Diode:600V 3A Dual
129631 Input Power EMI filter SA: HD4070 PWR SPLY
029316 TB1 INP-PWRSA: 200/2000/4X00/HD
129634 EBM main fan
041610 Power distribution board
108075 Fuse for power distribution board
003201 Main contactor
041613 Breakout board
041507 THC control board
229069 THC power supply
009858 Load resistor for THC power supply
041511 THC mortor drive board
041626 PC-104 power supply
041920 PC-104 stack
027647 Floppy drive
041605 Control PCB
108075 Fuse on control board
129633 P. S. Indicator light, Green
129632 P. S. Indicator light, White
003138 P. S. main current breaker
129621 Control transformer SA; HD4070, 480 V / 60 Hz
129622 Control transformer SA; HD4070, 240 V / 60 Hz
129623 Control transformer SA; HD4070, 400 V / 50–60 Hz
129624 Control transformer SA; HD4070, 200 V /50- 60 Hz
129625 Control transformer SA; HD4070, 440 V / 60 Hz
129626 Control transformer SA; HD4070, 220 V / 50–60 Hz
129627 Control transformer SA; HD4070, 600 V / 60 Hz
008317 125 amp fuse
109004 Hall effect sensor: 100A
041616 Plasma interface board
109201 Hall effect sensor: 500A
129485 Coolant flow subassembly with temp switch
004598 Coolant Filler Cap
027634 Filter Assembly
128909 Kit: HPR HD4070 Upgrade
Stromquelle
HD4070 – Mindesteinheiten zum Austausch
Brenner
