ANHANG D – SERVICE-BILDSCHIRM (NR. 18) STATUSTABELLE
d-2 HyPerformance HD4070 Betriebsanleitung
Port 0 Base Addr 224H Output Port 1 Base Addr 225H Input Port 2 Base Addr 226H Output
Bit 0 Select 160 amp Pin 47 Bit 0 Input power active Pin 31 Bit 0 DC output On/Off Pin 15
Bit 1 Select 80 amp Pin 45 Bit 1 Missing phase detect Pin 29 Bit 1 Slave 160 amp select Pin 13
Bit 2 Select 40 amp Pin 43 Bit 2 Chopper #1 temp OK Pin 27 Bit 2 Slave 80 amp select Pin 11
Bit 3 Select 20 amp Pin 41 Bit 3 Chopper #2 temp OK Pin 25 Bit 3 Slave 40 amp select Pin 9
Bit 4 Select 10 amp Pin 39 Bit 4 Temp_Airflow_OK Pin 23 Bit 4 Slave 20 amp select Pin 7
Bit 5 Select 1_10 current/ cable
checkCout
Pin 37 Bit 5 Output current OK Pin 21 Bit 5 Slave 10 amp select Pin 5
Bit 6 Fan control Pin 35 Bit 6 Slave input power active Pin 19 Bit 6 Slave 1_10 current Pin 3
Bit 7 Contactor control Pin 33 Bit 7 Slave missing phase detect Pin 17 Bit 7 Slave fan control Pin 1
Port 3 Base Addr 220H Input Port 4 Base Addr 221H Output Port 5 Base Addr 222H Input
Bit 0 Slave Chopper #1 temp OK Pin 47 Bit 0 Slave contactor control Pin 31 Bit 0 Plasma interface spare input Pin 15
Bit 1 Slave Chopper #2 temp OK Pin 45 Bit 1 Slave DC output On/Off Pin 29 Bit 1 Master_door_interlock Pin 13
Bit 2 Slave_Temp_Airflow_OK Pin 43 Bit 2 Pump control Pin 27 Bit 2 Cable_checkA_in Pin 11
Bit 3 Slave current OK Pin 41 Bit 3 Torch #1 coolant Pin 25 Bit 3 Slave_door_interlock Pin 9
Bit 4 Spare input Pin 39 Bit 4 Torch #2 coolant Pin 23 Bit 4 Cable_checkC_in Pin 7
Bit 5 Transfer sense Pin 37 Bit 5 Spare out Pin 21 Bit 5 Gas_error Pin 5
Bit 6 Coolant flow switch Pin 35 Bit 6 Transfer 1 Pin 19 Bit 6 Spare_in4 Pin 3
Bit 7 Coolant temp switch Pin 33 Bit 7 Spare_out2 Pin 17 Bit 7 Spare_in19 Pin 1
Port 6 Base Addr 50H Ouput Port 7 Base Addr 51H Input Port 8 Base Addr 52H Input
Bit 0 Spare_out14 Pin 47 Bit 0 Spare_in1 Pin 31 Bit 0 Spare_in11 Pin 15
Bit 1 Spare_out15 Pin 45 Bit 1 Spare_in2 Pin 29 Bit 1 Spare_in12 Pin 13
Bit 2 Spare_out16 Pin 43 Bit 2 Spare_in3 Pin 27 Bit 2 Spare_in13 Pin 11
Bit 3 Spare_out17 Pin 41 Bit 3 Spare_in6 Pin 25 Bit 3 Spare_in14 Pin 9
Bit 4 Spare_out7 Pin 39 Bit 4 Spare_in7 Pin 23 Bit 4 Spare_in15 Pin 7
Bit 5 Spare_out8 Pin 37 Bit 5 Spare_in8 Pin 21 Bit 5 Spare_in16 Pin 5
Bit 6 Spare_out20 Pin 35 Bit 6 Spare_in9 Pin 19 Bit 6 Spare_in17 Pin 3
Bit 7 Spare_out21 Pin 33 Bit 7 Spare_in10 Pin 17 Bit 7 Spare_in18 Pin 1
Port 9 Base Addr 200H Output Port 10 Base Addr 201H Output Port 11 Base Addr 202H Output
Bit 0 Transfer 2 Pin 47 Bit 0 Pilot arc relay Pin 31 Bit 0 Gas_state1 Pin 15
Bit 1 Transfer 3 Pin 45 Bit 1 Surge injection select Pin 29 Bit 1 Gas_state2 Pin 13
Bit 2 Select 5 amp Pin 43 Bit 2 Spare_out13 Pin 27 Bit 2 Gas_state3 Pin 11
Bit 3 Select 2 amp Pin 41 Bit 3 THC1 cycle start Pin 25 Bit 3 Spare_out19 Pin 9
Bit 4 Watchdog_out Pin 39 Bit 4 THC2 cycle start Pin 23 Bit 4 CNC_transfer Pin 7
Bit 5 Slave 5 amp select Pin 37 Bit 5 Analog6_check_out Pin 21 Bit 5 CNC_motion Pin 5
Bit 6 Slave 2 amp select Pin 35 Bit 6 Cable_checkA_out Pin 19 Bit 6 THC1_corner_hold Pin 3
Bit 7 Cable_checkB_out Pin 33 Bit 7 Spare_out18 Pin 17 Bit 7 THC2_corner_hold Pin 1
Port 12 Base Addr 204H Input Port 13 Base Addr 205H Input Port 14 Base Addr 206H Output
Bit 0 THC1 Retract complete Pin 47 Bit 0 CNC corner hold Pin 31 Bit 0 CNC ready to fire Pin 15
Bit 1 THC1 Cable install Pin 45 Bit 1 CNC plasma sync Pin 29 Bit 1 CNC arc transfer Pin 13
Bit 2 THC1 Discrete error Pin 43 Bit 2 CNC emergency stop Pin 27 Bit 2 CNC machine motion Pin 11
Bit 3 THC2 Retract complete Pin 41 Bit 3 CNC machine cable installedPin 25 Bit 3 CNC retract complete Pin 9
Bit 4 THC2 Cable installed Pin 39 Bit 4 CNC spare input Pin 23 Bit 4 CNC spare output Pin 7
Bit 5 THC2 Discrete error Pin 37 Bit 5 Watchdog_interlock Pin 21 Bit 5 CNC system error Pin 5
Bit 6 THC2 IHS complete Pin 35 Bit 6 THC1 IHS complete Pin 19 Bit 6 Serial Select1 Pin 3
Bit 7 CNC system start Pin 33 Bit 7 Cable_checkB_in Pin 17 Bit 7 Serial Select2 Pin 1
Serial Channels Addr 100H Analog Inputs Input
Com 1 Debug port 03F8H Channel Total current Pin 1
Com 2 Display serial 02F8H Channel Power Check Pin 2
Com 3 CNC Serial 03E8H Channel Not used Pin 3
Com 4 THC1/THC2 switched serial 02E8H Channel Not used Pin 4
Channel Not used Pin 7
Channel Not used Pin 8
Channel Analog6_check_in Pin 11
Channel Not used Pin 12
Eingang/Ausgang-Statustabelle
Die folgende Informationen sind für die Fehlerbeseitigung durch Servicetechniker. Sollte dem Techniker die
verwendete Terminologie nicht geläufig sein, sollte er sich mit der Europäischen Hypertherm-Organisation für
technische Unterstützung, Tel. 800 49 73 7843, in Verbindung setzen.
