ERSATZTEILELISTE
HyPerformance HD4070
Betriebsanleitung
6-13
Verschleißteilsatz
Teil-Nr.
Beschreibung
Menge
128946
Consumable Parts Kit
001579
Box: Gray Plastic
2
104119
HPR Consumable Tool
1
120025
Water Tube
1
026009
O-ring, .208 x .070
5
044028
O-ring, 1.364 x .070
2
027012
Lubricant: Silicon 2-Oz Tube
1
220173
Shield Retaining Cap with IHS Tab
1
220176
Nozzle Retaining Cap
2
220179
Swirl Ring: 130 Amp Mild Steel
1
220180
Swirl Ring: 30 Amp Mild Steel
1
220181
Electrode: 130 Amp Mild Steel
2
220182
Nozzle: 130 Amp Mild Steel
2
220183
Shield: 130 Amp Mild Steel
1
220187
Electrode: 80 Amp Mild Steel
1
220188
Nozzle: 80 Amp Mild Steel
1
220189
Shield: 80 Amp Mild Steel
1
220192
Electrode: 30 Amp Mild Steel
1
220193
Nozzle: 30 Amp Mild Steel
1
220194
Shield: 30 Amp Mild Steel
1
220197
Nozzle: 130 Amp Stainless Steel
1
220198
Shield: 130 Amp Stainless Steel
1
220201
Nozzle: 45 Amp Stainless Steel
1
220202
Shield: 45 Amp Stainless Steel
1
220304
Nozzle Retaining Cap (CCW)
1
220307
Electrode: 130 Amp Stainless Steel
4
220308
Electrode: 45 Amp Stainless Steel
1
220313
Nozzle Retaining Cap: 30 Amp
1
220337
Nozzle: 80 Amp Stainless Steel
1
220338
Shield: 80 Amp Stainless Steel
1
220339
Electrode: 80 Amp Stainless Steel
1
220340
Water tube: HPR
1
220352
Electrode: 200 Amp Mild Steel
3
220353
Swirl Ring: 200 Amp Mild Steel (CW)
1
220354
Nozzle: 200 Amp Mild Steel
3
220355
Nozzle Retaining Cap: 200 Amp Mild Steel (CW)
1
220356
Shield: 200 Amp Mild Steel
1
220398
Shield Retaining Cap: 200 Amp with IHS Tab
1
220342
Swirl Ring: 200 Amp Stainless Steel
1
220343
Nozzle: 200 Amp Stainless Steel
2
220344
Nozzle Retaining Cap: 200 Amp Stainless Steel
1
220345
Shield: 200 Amp Stainless Steel
1
220346
Nozzle: 200 Amp Aluminum
1
220347
Nozzle: 200 Amp Aluminum
1
004630
Electrode Pit Depth Gauge
1
Siehe
Verschleißteil-Übersicht vorher in diesem Abschnitt zwecks Aussehen und richtiger Kombinationen
der Verschleißteile.
