ERSATZTEILELISTE
6-8 HyPerformance HD4070 Betriebsanleitung
Teil Teil-Nr. Beschreibung Kennzeichnung Menge
1 129485 Solenoid Valve SA W/ Temp Switch TMP1 SV1, SV2, SV3 1
2 006113 Check Valve: 3/8 FTP CHV5 1
3 024538 Hose assembly: 3/8, Blue, 10 Inches 1
4 129620 Flow Switch Assembly FS1 1
5 011084 Sight Glass 1/4 NPT 1
6 024090 Hose assembly: 3/8, Blue, 20 Inches 1
7 027632 Radiator 1
8 024601 Hose assembly: 1/2, Black, 23 Inches 1
9 024749 Hose assembly: 1/2, Blue, 25 Inches
10 128714 Kit: Low Profile Filter 1
027927 Filter Element 1
11 031113 Motor 1
12 031138 Pump 1
128968 Kit: Coolant System Upgrade 1
13 024606 Hose assembly: 3/8, Blue, 12 Inches 2
14 128936 Kit: Coolant By-Pass 1
15 004598 Coolant Reservoir Cap 1
16 027664 Filter Element 1
17 027634 Filter Housing 1
Stromquelle
Kühlungssystem
4070.40c
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
