ScanControl 1612
- - 36
4. Configuration and attachment of the DMX-addresses of each unit
To enter the configuration menu, press button F1 (DMX button). In this menu you have the possibility to
adjust all parameters of the units in use. This menu contains:
Sc/P
select if you wish to configurate either a fixture or one of the 24 PAR-channels
Func
select for the configuration of dimmer/shutter-channel
Copy
select when a complete copy of a fixture configuration is required; (This will only be
shown on the display, if you activate the scan-button you want to assign the scan to and
if you assigned a not occupied x-channel to this button before.)
Example for a configuration of a light-equipment:
Your equipment consists e.g. of the following units:
1 Varyscan 4 1200 HMI
1 Varyscan 4 Compact 575 HMI
1 scan with DMX-configutration as follows:
channel 1 gobo
channel 2 y
channel 3 x
channel 4 colour
channel 5 iris
channel 6 dimmer
channel 7 shutter
channel 8 gobo rotation
channel 9 effect wheel
4 PAR 64 connected with a DMX-dimmer
First you have to enter the start address for each appliance:
Take care that you do not use any channel double.
Varyscan 4 1200 HMI
start address 1 (channels 1-8 used)
Varyscan 4 Compact 575 HMI start address 9 (channels 9-16 used)
scan with above described
configuration of channels
start address 17 (channels 17-25 used)
channel 1 address 17
channel 2 address 18
channel 3 address 19
channel 4 address 20
channel 5 address 21
channel 6 address 22
channel 7 address 23
channel 8 address 24
channel 9 address 25
PAR 64 Nr.1 start address 26 (use of channel 26)
PAR 64 Nr.2 start address 27 (use of channel 27)
PAR 64 Nr.3 start address 28 (use of channel 28)
PAR 64 Nr.4 start address 29 (use of channel 29)
Switch on the desk and press button More (F4) to enter the next section of the main menu. Press the
Init- button. You are requested to enter your password (see 3. How to do the setup) to activate the
configuration mode. After entering the correct password the configuration menu will show up. (If you
enter a wrong password, the display will switch back to the main menu). Press the DMX-button (F1) to
enter the configuration menu. Then select by pressing button Sc/P, whether you want to configurate
fixtures or dimmer-channels.
