ScanControl 1612
- - 43
Programming of time limits
At last you have to program the time limits
for scene No.1. Therefore press the button
Time in the section feature. By shifting the
joystick you have the possibility to adjust
setup- time and next- time. If you move the
joystick left/ right you can adjust setup-
time and if you move it up/ down, you can
adjust next-time. The setup-time is defined
as the period of time within parameters
such as X, Y, dimmer and iris are building
up a scene. The next- time is defined as
the period of time within the scene is
visible; i.e. if you edit two scenes which
have the setup-time 10 (1,0 second) and
the next-time 30 (3,0 seconds), the
parameters of x, y, iris and dimmer will built up scene no. 1. The next time will allow scene no. 1 to be
visible for another two seconds. After that the setup-time for scene no. 2 starts and the scene no. 2 will
be faded in. Both periods of time start at the same time, so please make sure that next-time is at the
same length or longer that the setup-time.
By pressing the button Time once more you can leave this feature
Add scenes to you program
Until now your program consisted of one scene only. To add another scene you have to inactivate all
feature functions. Then press button Insert. By pressing the button Insert you will add a new scene, to
your programm. This scene is a copy of the previous scene. Now change the required parameters like
you did in scene no. 1. Don´t forget to programm the time limits for scene no. 2.
If you have edited several scenes already, you can switch through them by shifting the joystick.
Your programm may have 24 scenes altogether.
Copy and delete scenes from a program
If a scene have to be deleted from your program (in case you do not like it or in case your programm
contains of too many scenes altogether), select the desired scene by shifting the joystick. Please take
care that none of the feature functions is activated. Then press the Delete-button and the scene is
deleted.
If you would like to copy a scene, select first the position where you want the copy of the scene located.
Then press the Copy-button and select by shifting the joystick the scene which should be copied. By
pressing the Execute-button the copy process is completed.
