ScanControl 1612
- - 48
If you want to link several program you have
to select the first program by pressing one
of the buttons from 1 to 24 (basic program).
The shift the joystick to choose the program
which should be linked to the first program.
Then press EXEC.
Your display will look like this:
Data storage on memory module
Press the button More in the main menu to call up the second section of the main menu. Press the
button Card. The functions of the memory module are password protected in order not to allow
unauthorized use. To get access to the menu enter your password.
The memory menu is divided in two sections:
Load
To transfer data from the
memory module into the
desk.
Save Store data from the desk onto
the memory module .
How to load data from memory module
After pressing the button Load, the display of
the desk will look like this.
Choose one of the functions
All
If you want to load all data from the memory module into the desk. The data of the
picture memory, the sequence memory of bank 1 and the setup memory of bank 1 is
loaded completely.
Pic
If you just want to load data of the picture memory from the memory module into the
desk
Seq
If you want to load data of the sequence memory completely or partly into the desk. As
your memory module enables you to store data in up to 3 complete sequence memories
(3*24 shutter sequences on bank B1 to B3), you can select with button Bank which of
the sequence memories is required. Either you can load data from one of three memory
banks completely, or you can load single shutter sequences directly. By pressing button
S/A you can choose whether you want to load all sequences (an A is displayed for all)
from the selected bank or only a certain sequence (S). If you want to load a certain
sequence you can select the basic sequence on the memory module by shifting the
joystick (left/right). Then select the point of destination for the sequence (up/down).
Confirm by pressing EXEC.
