On-Screen Display
G&D DVIMUX8-OSD-USB · 8
English
On-Screen Display
With the On-Screen Display (OSD), you can operate and configure the KVM switch.
Opening the On-Screen Display
The Hotkey+Num (default: Ctrl+Num ) key combination opens the OSD of the KVM
switch. The OSD is now displayed at the console monitor.
Layout of the On-Screen Display
The menus of the On-Screen Display comprise three main parts.
 The Header  shows the name of the current menu.
 The List field  displays the computers to be accessed or the menu entries of the cur-
rently opened menu.
 The Footer  shows the keys to operate the menu that is currently displayed.
ADVICE: If you apply Microsoft‘s »IntelliMouse Explorer« or another compatible
mouse, you can open the On-Screen Display (see page 38) with the additional
mouse keys.
SELECT COMPUTER DVIMUX8
CPU 1 1
CPU 2 2
...
CPU 8
8
Esc Enter F1:Menu



