On-Screen Display

G&D DVIMUX8-OSD-USB · 10

English

Changing the On-Screen Display settings

The

List field

of the On-Screen Display provides different types of menu entries:

Configuration settings:

The setting that is currently

active is displayed in the right column. Press the

Space

key (repeatedly) to select between the options.

After you change the configuration settings of a menu, press

F1

to save your settings

and return to the top menu.

Context menus:

If a menu bar is too short to dis-

play a name or option, the entries are displayed in

a context menu.

Choose the menu bar you want to enable/disable and press

Space

. Confirm your set-

tings with

Enter

and leave the menu.

Submenus:

Submenus group configuration settings

and detailed information according to topic.

Submenus are highlighted by three dots in the right column. Press

Enter

to open a

submenu. The

Footer

shows the key to close the submenu.

Text boxes:

Use the keyboard to enter text. This

overwrites the existing entry.

Confirm your entries by pressing

Enter

.

Menu entries in different colours

The

List field

entries have different colours:

White:

name of the menu entry

Light blue:

disabled menu entry (check user rights if necessary)

Yellow:

settings the user can edit

Green:

active computer (in list field of Select Computer menu)

Red:

inactive computer (in list field of Select Computer menu)

ADVICE:

You can also press

Enter

to edit the text.

Hotkey:

CTRL

PixelPower Clarity (blue)

X

SKIDATA 1

USB Keyboard Mode

...

Console Name:

'9,

MUX
