DVI-CON « User modules
51 · G&D DVICenter DP32
Back panel
The Transmission interface at the back panel of the user module provides additional
status LEDs, which have the following functions:
TradeSwitch-LED
The optional TS-LED (order number A6100041) lights if the key-
board and mouse signals of a master console are accessing the user
module.
LED Colour Status Meaning
left Yellow off No connection to network.
blinking Network connection to an end device.
right Green on A user module is accessing the target module.
blinking No communication with matrix switch.
flashing Connection to matrix switch established.
No user module is accessing.
flickering Keyboard and mouse inputs are forwarded by the accessing
user module.
The flickering is defined by the user’s entries.
Yellow flashing A firmware update is carried out.
NOTE: Keyboard and mouse signals can only access another user module or a tar-
get computer if you purchased the TradeSwitch function for the matrix switch.
