User module
»
DVI-CON
G&D DVICenter DP32 · 52
Technical data
Interfaces to
console:
Video:
1 × DVI-I (DVI Single-Link or VGA)
Keyboard and mouse signals:
2 × PS/2 socket
2 × USB-A
Audio:
2 × 3,5 mm jack socket
Tradeswitch-LED:
1 × D-SUB 9 socket
Data transmission to
central module
Interface:
1 × RJ45 socket
Transmission length:
Max. 140 meters
Video
Resolution @ 60 Hz:
Max. 1920 × 1200 pixels
Resolution @ 85 Hz:
Max. 1280 × 1024 pixels
Colour depth:
24 bits
Pixel rate:
25 MHz to 165 MHz
Vertical frequency:
50 Hz to 180 Hz
Horizontal frequency:
30 kHz to 130 kHz
Norms:
DVI 1.0, E-DDC
Audio
Type:
Bi-directional extension
Resolution:
24 Bit
Sampling rate:
96 kHz
Bandwidth:
22 kHz
Main power supply
Type:
Internal power pack
Connection:
1 × IEC plug(IEC-320 C14)
Current consumption:
100 - 240 VAC; 0.3 A - 0.2 A
Redundant
power supply
optional
Type:
External power pack (12 V/2 A)
Connection:
1 × Mini-DIN 4 socket(Power In)
Current consumption:
12 VDC; 1.2 A
Casing
Material:
Anodised aluminium
Dimensions (W × H × D):
210 × 44 × 210 mm
Weight:
Approx. 1,2 kg
Operating
environment
Temperature:
+5 to +45 °C
Air humidity:
< 80%, non-condensing
Conformity
CE, RoHS
