Status displays « Central Module
27 · G&D DVICenter DP32
Status displays
LEDs at the front panel
The LEDs on the front panel of the matrix switch show the system’s operating status:
Section
LED
Status
Meaning
Ident.
Ident.
on
LED to identify the device in the web application is active.
blinking
Port type at Dynamic Ports is shown.
Power
Red.
on
The power pack is turned on and supplies the required voltage.
off
The power pack is turned off or the connection to the mains
could not be established.
Main
on
The power pack is turned on and supplies the required voltage.
off
The power pack is turned off or the connection to the mains
could not be established.
Status
Ready
blinking
The network subsystem works properly.
off
The network functionality is not supported.
Switch
blinking
The matrix switch is ready for operation.
