Central module » Expanding switchable signals
G&D DVICenter DP32 · 26
How to connect a stack matrix switch:
1. Use a category 5e (or better) twisted pair cable to connect the
Bus In
interface of
the new satellite matrix switch to the
Bus Out
interface of the “last” satellite or pri-
mary matrix switch.
2. Check and change the bus address of the stack matrix switch, if required (see
Adjusting the bus address of matrix switches
The primary matrix switch automatically makes the stack matrix switches access the
same port that the user accesses at the primary matrix switch.
This requires the correct setting of the bus address in the individual matrix switches.
How to change the bus address of a matrix switch:
1. Press
Ctrl
(default) to open the on-screen display.
2. Press
F11
to call the Configuration menu.
3. Choose
System
and press
Enter
.
4. Choose
Bus address
and press
F8
to select one of the following options:
5. Press
F2
to save your settings.
NOTE:
The primary and the last stack matrix switch may be placed up to 100
metres apart.
primary:
The central module is operated by the user.
It switches the satellite matrix switches automatically.
satellite 1 … 9:
Assign the addresses continuously to the individual stacking
matrix switches.
