User modules » U2-R-CON

G&D DVICenter DP32 · 54

USB 2.0 Devices:

Connect up to 4 USB devices to these interfaces.

Power In:

Connect the power cable to the power pack and a power outlet.

Status displays

The blinking Transmission LEDs show the following connection statuses:

ADVICE:

You can establish a direct connection between a target and a user module of

the network fails or a port at the central module does not work properly.
Use a category 5e (or better) crossover cable to connect both modules.

LED

Colour

Status

Meaning

Left

Yellow

Off

No connection to network.

On

A user module is accessing the target module.

Right

Green

On

A user module is accessing the target module.

Blinking

No communication with central module.

Flashing

Connection to central module established successfully.

No user module is accessing.
