U2-R-CON « User module
55 · G&D DVICenter DP32
Technical data
Interfaces to
target computer:
USB 2.0: 4 × USB-A
RS232: 1 × D-SUB 9 socket
Data transmission to
central module
Interface: 1 × RJ45 socket
Transmission length: Max. 140 metres
USB 2.0 Transmission type: Transparent
Transmission rate: Max. 480 Mbit/s
RS232 Transmission type: Transparent
Transmission rate: Max. 115,200 bit/s
Signals: RxD, TxD, RTS, CTS, DTR, DSR, DCD
Main power supply Type: Portable power pack
Connector: 1 × Mini-DIN 4 socket
Power consumption: 12 VDC/1.5 A
Housing Material: Anodised aluminium
Dimensions (W × H × D): 105 × 26 × 104 mm
Weight: Approx. 240 g
Operational 
environment
Temperature: + 5 to + 40°C
Air humidity: < 80%, non condensing
Conformity CE, RoHS
