Central module » Expanding switchable signals
G&D DVICenter DP32 · 24
Deleting a multichannel configuration
How to delete a multichannel configuration:
1. In the directory tree, click KVM matrix systems > [Name] > DVI-CONs or DVI-CPUs .
2. Right-click a user or computer module you want to delete from a multichannel con-
figuration.
3. On the context menu, click Multichannel configuration .
The current configuration is shown.
4. In the right column ( Assigned ), click a module that is assigned to one of the 2 to 8
channels or to the USB/RS232 channel.
Click (arrow left) to delete the module’s assignment.
5. Repeat step 4 to delete the assignment of other modules.
6. Click OK if only one module is left assigned to KVM channel 1.
The multichannel configuration is deleted.
NOTE: The web application deletes a multichannel configuration if it does bot
contain any other channels than KVM channel 1.
