Expanding the KVM matrix system by cascading « Central Module
19 · G&D DVICenter DP32
In the second cascade level, you can increase the number of computers as follows :
Connecting a slave central module
How to connect a slave central module to a master device:
1. Configure one Dynamic Port for connecting the user modules of the slave central
modules for each console that is to be accessing the slave central module simulta-
neously.
You should therefore proceed as described on page 15.
2. Connect the configured Dynamic Ports for accessing user modules to Dynamic Ports
for accessing the target modules of the master device.
Use regular CAT5 twisted pair cables to connect the central modules.
3. Connect the target modules or other slave central modules to the slave central
module (up to 2 cascade levels).
4. Check and, if necessary, change the cascade mode of the master and/or the slave
central module (see page 20).
Consoles Computers Central modules Consoles Computers Central modules
1 – – 17 227 7
2 – – 18 214 7
3 – – 19 201 7
4 – – 20 188 7
5 – – 21 175 7
6 4.738 91 22 82 3
7 3.657 73 23 77 3
8 2.744 57 24 72 3
9 1.987 43 25 67 3
10 1.374 31 26 62 3
11 893 21 27 57 3
12 852 21 28 52 3
13 507 13 29 47 3
14 482 13 30 42 3
15 457 13 31 37 3
16 432 13 32 - -
NOTE: The master device can be placed up to 140 metres away from the slave
central module.
