The »DVICenter« KVM matrix system

G&D DVICenter DP32 · 2

The »DVICenter« KVM matrix system

KVM matrix systems of the DVICenter series consist of at least one central module,

one user module and one target module.

The central module of the DVICenter series is the central device of the KVM matrix

system. Both target and user modules are connected to the central module.

You can use the KVM matrix system to access a target module with a user module.

By accessing the computer that is connected to the target module, the video image is

displayed at the console monitor. You can now operate the accessed computer with

console keyboard and console mouse.

The 32 Dynamic Ports can be configured in order to connect a user module or a target

module. In the default setting, the ports 1 to 8 are configured for connecting the user

modules. The ports 9 to 32 are configured for connecting the target modules.

By cascading the KVM matrix system, the number of target modules can be increased.

Detailed information regarding this topic is given on page 18 ff.

The installation of devices of the KVM matrix system is described in the following

paragraphs.

NOTE:

You can change the port assignment as described on page 14.
