STANDARD-KOMPONENTEN
MAX200
(Handbrenner) Betriebsanleitung
6-3
Teile-
Position
nummer
Beschreibung
Kennzeichnung
Menge
029319
Panel, Control SA
1
041536
PCB, interlock display SA
1
009063
Diode, LED, amber
LED 1-7
7
2
005041
Switch, toggle DPDT
S1
1
3
022008
Gauge, pressure 0-100 psi
PG1
1
4
022008
Gauge, pressure 0-100 psi
PG2
1
5
006038
Valve, needle .188 orifice
V6
1
6
006027
Valve, needle .125 orifice
V5
1
7
001222
Panel, control
1
8
005121
Pushbutton, green, illmn.
PB1
1
9
005122
Pushbutton, red, extended
PB2
1
10
005088
Holder, lamp
1
005168
Bulb, 28VDC
1
005089
Lens, white for 005088
1
11
-
Not applicable to hand torch system.
12
-
Not applicable to hand torch system.
13
029360
Panel, thumbwheel/machine delay SA
1
14
005123
Thumbwheel
S3
1
15
009604
Resistor, variable, 100 K, 1 turn
R9
1
